SDEC Power-Shanghai Diesel Engine Co., Ltd

Shanghai Diesel currently has eight series of high-quality diesel and natural gas engines including R, H, D, C, E, G, W, and Z. The power range covers 50-1600 horsepower, which are mainly used in trucks, buses, construction machinery, agricultural machinery, Power equipment for power stations, ships and other equipment.

Wide Product Ranges-Power Range Between 8kW to 2176kW

As one of the largest indepent engine manufacturer in China, SDEC power have 11 products series, covers the power range between 8kW to 2176kW, SDEC products has been widely used in truck, bus, construction equipment, passensger vehicle, generator set, maritime, agricultural euqipment and water pump set.

Joint Venture with Mitsubishi and FPT

As the leading engine manufacturer in China, SDEC owns a 1 million square meter factory with modern highly automated production line in Shangha, SDEC has more than 9,500 employees, the strong foundation of SDEC attractive international leading company including Mitsubishi and FPT to set up joint venture with SDEC power in China.

11 Series Engine Products.

SDEC Power now producing 11 series of diesel and gas engines including Z、M、R、H、D、C、E、G、K、W、SR, covering the power range of 8kW to 2176kw. SR series engines are the Mitsubishi S6R, S12R and S16R series diesel engine that using for industrial generator set, which meet the US EPA2 emissions and IMO2 emissions marine diesel engines.

A Power System Solution Provider

As official exporting agent of SDEC Power, EMAC supplying complete power system that integrated with cooling, air intake, exhuast, control system, and other customize developed accessories, EMAC is the reliable and professional one-stop solution provider that you can fully trust.

A Professional Trustworthy Chinese Company

13+ years of experience, with more than 1000 delivered projects, EMAC is the professional partner you can fully trust, We Know What You Need!
Based on the rich resouce we have here in China, EMAC offers partner best matching solutions with quality orientied, as we clearly understand reputation is the the foundation of our existence as well as the driven power of our future growth.

SDEC Company Introduction Video on Youtube
EMAC Group Limited was established in Hong Kong in 2010, aims to become a solid one-stop supplier in the power machinery industry. EMAC operating four overseas subsidiaries and owns 10 self-registered trademarks, our products are widely used in which covers energy, maritime, automotive, construction, railways and spare parts. Based on different types of DCEC engines, EMAC integrate other leading power system products into a complete power system.
With years of rich powertrain supply experience, EMAC can quickly understand and respond to customer needs, greatly reducing customer communication costs.
EMAC provides one-stop solutions covers from pre-design to components supply, from installation… Read More
SDEC Power Automobile Technology Co., Ltd. (former name: Shanghai Diesel Engine Co., Ltd.,), was founded in 1947 and is now affiliated to SAIC Motor. The company has “SAIC Hongyan” brand tractors, trucks, special vehicles, dump trucks and heavy truck products; has “Shangchai Power” brand M, R, H, D, C, E, G, K, W and other nine Large series of high-quality diesel and natural gas engines and generator sets; CURSOR9 (8.7L), CURSOR11 (11.12L), CURSOR13 (12.87L) and other series of diesel engines with the “Shangfeihong” brand; S6R2 with the “SME-Shanghai Mitsubishi Engine” brand /S12R/S16R series diesel engines; The company’s products cover the whole country and have a global layout. It has a relatively complete marketing service network and convenient and thoughtful service… Read More
With the mission of “Better Power, Better World”, EMAC gathering a brilliant well-educated team, all of EMAC’s team members are have English background, from sales to engineers, from marketing team to administration team, our good English foundation ensuing the ability of smooth communication with all customers.
EMAC also gradually builing our global services network, from branch companies to joint ventures, from local sales representatives to local after-sales services partners, we continuously expanding a global network that to provide better communication and services for our customers.
Till 2021, EMAC have branch companies and joint venture in Thailand and Singapore with after-sales service ability in this two countries. And we have sales representatives in Turkey, Spain, France and UK… Read More

As a 12 years experience profesional one-stop power system provider, EMAC have unique excellent ability with supplying complete power system for all kinds of applications.
From automotive powertrain system to industrial engine power system, from water pump drive package to complete generator set, from marine propulsion system to marine power system, by working closely with global leading companies’ factories in China, EMAC gives high-end solutions with competitive prices.
EMAC is excellent solution provider with a professional and dedicated team, we developed our advanced management system based on our past experience, and EMAC is the innovator of detailed visulization services that have professional video…Read More

We cares your voice, from pre-sales communications, to sales communications, from after-sales complaints to customer review feedback, EMAC continuously collecting all kinds of qustions from customers, no matter questions on products, about business terms, marketing or manament related, helping EMAC and customers to know each other better and grow up together.
With the mission of “Better Power, Better World”, and the vision of “Help World Leverage the Power of China”, EMAC looking for business partners in each country, that can working both as branch company or joint venture, by leverage the rich resources here, business network and local service advantages in China, we hope can help all manufacturers in the world to improve their design ability, manufacturing capability, management… Read More
SDEC-Automotive-Engine-Application-scenario-picture

Automotive Engine

The SDEC Power automotive engine adopts a V-shaped structure, which shortens the axial dimension, reduces the overall height and length, and is beneficial to the space layout in the vehicle. Except for the small generator driven by a belt, the rest components are internal gear driven, which effectively improves the engine capacity. Reliability, reduce the possibility of failure of the whole vehicle.

FIND MORE

SDEC-Industrial-Engine-Application-scenario-picture

Industrial Engine

High degree of serialization, good versatility, less maintenance spare parts, easy maintenance and repair. The SDEC Power automotive engine adopts V-shaped structure, which shortens the axial dimension and reduces the overall height. It has excellent low-temperature performance, and the minimum starting temperature can reach -32 ℃ .Suitable for 24-hour full-load work and harsh environmental conditions, it can also operate reliably in high-temperature deserts ares.

FIND MORE

SDEC-Pump-Engine-Application-scenario-picture-06-1100x600-1

Pump Engine

SDEC Power water pump drive engines has four valves structure, high strength, integral cylinder head design, key components adopt international first-class brand, high reliability and good economical efficiency. According to SAIC MOTOR manufacturing standards, Germany’s Volkswagen engine quality control system guarantee, high quality products and good consistency. Overall structure using component integration design, basic parts diesel engine was 20% less than normal, structure is simple, maintenance is convenient.Meet the road II emissions standards.

FIND MORE

SDEC-Generator-Drive-application-scenario-Picture-05-1100X6001

G-Drive Engine

SDEC Power generator drive engine adopts an integral crankshaft, a gantry body, a flat cut connecting rod, and a short piston, with a compact and reasonable shape. It has excellent power, economy, stability, reliability, operability and low operation and maintenance costs. It adopts a new type of shrinking combustion chamber, increases the fuel injection pressure, improves the combustion process, and achieves environmental protection indicators. Its quality has been recognized by users.

FIND MORE

SDEC-Marine-Engine-Application-scenario-picture

Marine Engine

The layout design of the inner water channel and the inner oil channel is adopted to reduce the number of external pipes and improve the reliability of the whole SDEC Power marine engine. The diesel engine is sprayed with conformal paint before leaving the factory, and the exposed processing surface is sprayed with anti-rust primer, which can meet the normal work in the environment of humid air, salt spray, oil mist and mold.

FIND MORE

SDEC-Gas-G-Drive-Engine-application-scenario-Picture-1100X600

Gas Engine

As the leading company in gas engine fields, SDEC Power gas engines has been in mass production since the year of 2003, after 20 years of researching and developing, SDEC Power gas engines has been widely used in truck, bus, van, pick up, SDEC Power gas engines has been proven its high quality standard and high reliability in all harsh environment, including high altitude, alpine region and tropical area.

FIND MORE

Find Engines by Series or Type

Below list is the engines classified by engine type, you can also find engines classified by series in the top menu.

Automotive Engine

R Automotive147-154 kW
E Automotive221-426 kW
H Automotive 147-243 kW
SC25R Automotive96-110 kW
F Automotive 324-382 kW
Y Automotive
D25 Automotive 118 kW

Engine Model

Power/kW

01503004506007509001050
SDEC Automotive Engine Catalogue
Series
Model

R
SC10E300Q6 | 221 kW @ 1900 RPMSC10E330Q6 | 243 kW @ 1900 RPMSC10E3700Q6 | 272 kW @ 1900 RPMSC10E400Q6 | 294 kW @ 1900 RPM
SC10E420Q6 | 309 kW @ 1900 RPMSC12E420Q6 | 309 kW @ 1900 RPMSC12E440Q6 | 323 kW @ 1900 RPMSC12E450Q6 | 331 kW @ 1900 RPM
SC12E460Q6 | 338 kW @ 1900 RPMSC12E480Q6 | 353 kW @ 1900 RPMSC13E500Q6 | 368 kW @ 1800 RPMSC13E520Q6 | 382 kW @ 1800 RPM
SC13E540Q6 | 391 kW @ 1800 RPMSC13E560Q6 | 412 kW @ 1800 RPMSC13E580Q6 | 426 kW @ 1800 RPM
SC4H210Q6 | 154 kW @ 2500 RPMSC4H180Q6 | 135 kW @ 2500 RPMSC4H160Q6 | 120 kW @ 2500 RPM SC4H140Q6 | 103 kW @ 2500 RPM
SC7H290Q6 | 213 kW @ 2300 RPMSC7H270Q6 | 199 kW @ 2300 RPMSC7H250Q6 | 184 kW @ 2300 RPMSC7H230Q6 | 170 kW @ 2300 RPM
SC7H215Q6 | 158 kW @ 2300 RPMSC7H200Q6 | 147 kW @ 2300 RPMSC4H220Q6 | 162 kW @ 2300 RPMSC7H330Q6 | 243 kW @ 2300 RPM
SC25R130Q6A丨96 kW @ 3000 RPM SC25R150Q6A丨110 kW @ 3000 RPM

F

Y
——END——

coming soon...

coming soon...

coming soon...

coming soon...

coming soon...

coming soon...

coming soon...

Industrial Engine

C Industrial135-235 kW
D Industrial132-265 kW
E Industrial162-412 kW
H Industrial66-268 kW

Engine Model

Power/kW

01503004506007509001050
SDEC Industrial Engine Catalogue
Series
Model

C

SC11CB184 | 135 kW @ 1850 RPM SC11CB195 | 140 kW @ 1900 RPM SC11CB200 | 147 kW @ 2200 RPM SC11CB200.1 | 147 kW @ 1850 RPM
SC11CB220 | 162 kW @ 2200 RPMSC11CB220.1 | 162 kW @ 2100 RPM SC11CB220.2 | 162 kW @ 2000 RPM SC11CB240 | 175 kW @ 2200 RPM
SC11CB240.1 | 175 kW @ 2000 RPM SC11CB270 | 200 kW @ 2200 RPM
SC9DF360G4 | 265 kW @ 2200 RPMSC9DF360.1G4 | 265 kW @ 2000 RPMSC9DF360.4G4 | 250 kW @ 2100 RPMSC9DF340.4G4 | 250 kW @ 2100 RPM
SC9DF330G4 | 243 kW @ 2200 RPMSC9DF330.1G4 | 243 kW @ 2000 RPMSC9DF330.2G4 | 243 kW @ 1800 RPMSC9DF330.4G4 | 243 kW @ 2100 RPM
SC9DF320G4 | 236 kW @ 2200 RPMSC9DF300G4 | 221 kW @ 2200 RPMSC9DF290G4 | 214 kW @ 2200 RPMSC9DF290.1G4 | 214 kW @ 2000 RPM
SC9DF290.2G4 | 214 kW @ 1800 RPMSC9DF280G4 | 206 kW @ 2200 RPMSC9DF270G4 | 199 kW @ 2200 RPMSC9DF270.1G4 | 199 kW @ 2000 RPM
SC9DF260G4 | 192 kW @ 2200 RPMSC9DF260.1G4 | 192 kW @ 2000 RPMSC9DF260.2G4 | 192 kW @ 1800 RPMSC9DF250G4 | 184 kW @ 2200 RPM
 SC9DF240G4 | 177 kW @ 2200 RPM SC9DF240.1G4 | 177 kW @ 2000 RPM SC9DF240.2G4 | 177 kW @ 1800 RPM SC9DF230G4 | 170 kW @ 2200 RPM
SC9DF230.1G4 | 170 kW @ 2000 RPMSC9DF230.2G4 | 170 kW @ 1800 RPMSC9DF220G4 | 162 kW @ 2200 RPMSC9DF220.1G4 | 162 kW @ 2000 RPM
 SC9DF220.2G4 | 162 kW @ 1800 RPM SC9DF210G4 | 155 kW @ 2200 RPM SC9DF190.4G4丨140 kW @ 1800 RPM SC9DF180.4G4丨132 kW @ 1800 RPM
SC10E360G4 | 265 kW @ 2200 RPMSC10E360.1G4 | 265 kW @ 2000 RPMSC10E340G4 | 250 kW @ 2200 RPMSC10E340.1G4 | 250 kW @ 2000 RPM
SC10E320G4 | 235 kW @ 2200 RPMSC10E320.1G4 | 235 kW @ 2000 RPMSC10E300G4 | 221 kW @ 2200 RPMSC10E300.1G4 | 221 kW @ 2000 RPM
SC10E280G4 | 206 kW @ 2200 RPMSC10E280.1G4 | 206 kW @ 2000 RPMSC10E260G4 | 192 kW @ 2200 RPMSC10E260.1G4 | 192 kW @ 2000 RPM
SC10E240G4 | 177 kW @ 2200 RPMSC10E240.1G4 | 177 kW @ 2000 RPMSC10E230G4 | 170 kW @ 2200 RPMSC10E230.1G4 | 170 kW @ 2000 RPM
SC10E220G4 | 162 kW @ 2200 RPMSC10E220.1G4 | 162 kW @ 2000 RPMSC13E560G4 | 412 kW @ 1900 RPMSC13E500G4 | 368 kW @ 1900 RPM
 SC13E480G4 | 353 kW @ 1900 RPM SC13E460G4 | 338 kW @ 1900 RPM SC13E420G4 | 309 kW @ 1900 RPM SC13E400G4 | 294 kW @ 2000 RPM
SC13E380G4 | 279 kW @ 2000 RPMSC13E360G4 | 265 kW @ 2000 RPMSC13E340G4 | 250 kW @ 2000 RPMSC13E320G4 | 235 kW @ 2000 RPM
SC4H180G4-I | 129 kW @ 2200 RPMSC4H160G4-I | 118 kW @ 2200 RPMSC4H160.1G4 | 118 kW @ 2000 RPMSC4H160.2G4-I | 118 kW @ 1800 RPM
 SC4H155G4 | 113 kW @ 2200 RPMSC4H150G4 | 110.3 kW @ 2200 RPMSC4H140G4-I | 103 kW @ 2200 RPMSC4H140.3G4 | 103 kW @ 2300 RPM
SC4H140.2G4-I | 103 kW @ 1800 RPMSC4H140.1G4-I | 103 kW @ 2000 RPMSC4H135.3G4 | 99.3 kW @ 2300 RPMSC4H130G4-I | 95.6 kW @ 2200 RPM
SC4H130.1G4-I | 95.6 kW @ 2000 RPMSC4H130.3G4-I | 95.6 kW @ 2300 RPMSC4H125G4-I | 92 kW @ 2200 RPMSC4H125.1G4-I | 92 kW @ 2000 RPM
SC4H125.2G4-I | 92 kW @ 1800 RPMSC4H125.3G4-I | 92 kW @ 2300 RPMSC4H120.3G4 | 88.2 kW @ 2300 RPMSC4H115G4-I | 85 kW @ 2200 RPM
SC4H115.1G4 | 85 kW @ 2000 RPMSC4H115.3G4 | 85 kW @ 2300 RPMSC4H110G4 | 81 kW @ 2200 RPMSC4H110.3G4 | 81 kW @ 2300 RPM
SC4H110.2G4 | 81 kW @ 1800 RPMSC4H105.3G4 | 77.3 kW @ 2300 RPMSC4H100G4-I | 73.5 kW @ 2200 RPMSC4H100.1G4-I | 73.5 kW @ 2000 RPM
SC4H100.2G4 | 73.5 kW @ 1800 RPMSC4H100.3G4 | 73.5 kW @ 2300 RPMSC4H95.3G4 | 70 kW @ 2300 RPMSC4H90.3G4 | 66.2 kW @ 2300 RPM
SC4H190G4-I | 129 kW @ 2200 RPMSC4H190.1G4-I | 129 kW @ 2000 RPMSC4H190.2G4-I | 129 kW @ 1800 RPMSC4H180G4-II | 129 kW @ 2200 RPM
SC4H180.1G4-I | 129 kW @ 2000 RPMSC4H180.2G4-I | 129 kW @ 1800 RPMSC4H175G4 | 129 kW @ 2200 RPM SC4H170G4 | 125 kW @ 2200 RPM
SC4H160G4-II | 118 kW @ 2200 RPMSC4H160.1G4-I | 118 kW @ 2000 RPMSC4H160.2G4-II | 118 kW @ 1800 RPMSC4H140G4-II | 103 kW @ 2200 RPM
SC4H140.1G4-II | 103 kW @ 2000 RPMSC4H140.2G4-II | 103 kW @ 1800 RPMSC4H130G4-II | 95.6 kW @ 2200 RPMSC4H130.1G4-II | 95.6 kW @ 2000 RPM
SC4H130.3G4-II | 95.6 kW @ 2300 RPMSC4H125G4-II | 92 kW @ 2200 RPMSC4H125.1G4-II | 92 kW @ 2000 RPMSC4H125.2G4-II | 92 kW @ 1800 RPM
SC4H125.3G4-II | 92 kW @ 2300 RPMSC4H115G4-II | 85 kW @ 2200 RPMSC4H100G4-II | 73.5 kW @ 2200 RPM SC4H100.1G4-II | 73.5 kW @ 2000 RPM
SC4H220G4 | 162 kW @ 2200 RPMSC4H220.1G4 | 162 kW @ 2000 RPMSC4H200G4 | 147 kW @ 2200 RPMSC4H200.1G4 | 147 kW @ 2000 RPM
SC4H200.2G4 | 147 kW @ 1800 RPMSC4H190G4-II | 140 kW @ 2200 RPMSC4H190.1G4 | 140 kW @ 2000 RPMSC4H190.2G4-II | 140 kW @ 1800 RPM
SC4H180G4-III | 132.5 kW @ 2200 RPMSC4H180.1G4-II | 132.5 kW @ 2000 RPMSC4H180.2G4-II | 132.5 kW @ 1800 RPMSC4H160G4-III | 118 kW @ 2200 RPM
SC7H260G4-I | 191.5 kW @ 2200 RPMSC7H250G4-I | 184 kW @ 2200 RPMSC7H240G4-I | 177 kW @ 2200 RPMSC7H230G4-I | 169 kW @ 2200 RPM
SC7H220G4-I | 162 kW @ 2200 RPMSC7H220.1G4-I | 162 kW @ 2000 RPMSC7H215G4 | 158.5 kW @ 2200 RPMSC7H210G4 | 155 kW @ 2200 RPM
SC7H210.1G4 | 155 kW @ 2000 RPMSC7H200G4-I | 147 kW @ 2200 RPMSC7H200.1G4-I | 147 kW @ 2000 RPMSC7H200.2G4-I | 147 kW @ 1800 RPM
SC7H195G4 | 143.5 kW @ 2200 RPMSC7H190G4 | 140 kW @ 2200 RPMSC7H190.1G4-II | 140 kW @ 2000 RPMSC7H190.2G4 | 140 kW @ 1800 RPM
SC7H190.4G4 | 140 kW @ 2200 RPM SC7H185.4G4 | 132.5 kW @ 2200 RPMSC7H185G4 | 136 kW @ 2200 RPMSC7H185.1G4 | 136 kW @ 2000 RPM
SC7H185.2G4 | 136 kW @ 1800 RPMSC7H180G4 | 129 kW @ 2200 RPMSC7H180.1G4 | 129 kW @ 2000 RPMSC7H180.2G4 | 129 kW @ 1800 RPM
SC7H175G4 | 129 kW @ 2200 RPMSC7H175.1G4 | 129 kW @ 2000 RPMSC7H175.2G4 | 129 kW @ 1800 RPMSC7H175.3G4 | 127 kW @ 2200 RPM
SC7H175.4G4 | 129 kW @ 2100 RPMSC7H170G4 | 125 kW @ 2200 RPMSC7H170.1G4 | 125 kW @ 2000 RPMSC7H165G4 | 122 kW @ 2200 RPM
SC7H165.3G4 | 122 kW @ 2300 RPMSC7H160G4 | 118 kW @ 2200 RPMSC7H160.1G4-II | 118 kW @ 2000 RPMSC7H160.2G4 | 118 kW @ 1800 RPM
SC7H160.3G4 | 118 kW @ 2300 RPMSC7H160.4G4 | 121 kW @ 2200 RPMSC7H155G4 | 114 kW @ 2200 RPMSC7H155.3G4 | 114 kW @ 2300 RPM
SC7H150G4 | 110.3 kW @ 2200 RPMSC7H150.1G4 | 110.3 kW @ 2000 RPMSC7H150.2G4 | 110.3 kW @ 1800 RPM SC7H150.3G4 | 110.3 kW @ 2300 RPM
SC7H150.4G4 | 115 kW @ 2200 RPM SC7H145G4 | 107 kW @ 2200 RPMSC7H145.4G4 | 107 kW @ 1900 RPMSC7H145.3G4 | 107 kW @ 2300 RPM
SC7H140G4 | 103 kW @ 2200 RPMSC7H140.3G4 | 103 kW @ 2300 RPMSC7H135.3G4 | 99.3 kW @ 2300 RPMSC7H135G4 | 99.3 kW @ 2200 RPM
SC7H130G4 | 95.6 kW @ 2200 RPMSC7H130.3G4 | 95.6 kW @ 2300 RPMSC7H125.1G4 | 92 kW @ 2000 RPMSC7H125G4 | 92 kW @ 2200 RPM
SC7H125.3G4 | 92 kW @ 2300 RPMSC7H120G4 | 88.2 kW @ 2200 RPMSC7H120.3G4 | 88.2 kW @ 2300 RPM SC7H310G4 | 228 kW @ 2200 RPM
SC7H290G4 | 213.5 kW @ 2200 RPMSC7H290.1G4 | 213.5 kW @ 2000 RPMSC7H280G4 | 206 kW @ 2200 RPMSC7H275G4 | 202.5 kW @ 2200 RPM
SC7H260G4-II | 191.5 kW @ 2200 RPM SC7H260.1G4 | 191.5 kW @ 2000 RPMSC7H250G4-II | 184 kW @ 2200 RPMSC7H240G4-II | 177 kW @ 2200 RPM
SC7H240.1G4 | 177 kW @ 2000 RPM SC7H230G4-II | 169.5 kW @ 2200 RPMSC7H220G4-II | 162 kW @ 2200 RPMSC7H220.1G4-II | 162 kW @ 2000 RPM
SC7H200G4-II | 147 kW @ 2200 RPMSC7H200.1G4-II丨147 kW @ 2000 RPMSC7H200.2G4-II丨147 kW @ 1800 RPM
——END——

coming soon...

coming soon...

coming soon...

coming soon...

Pump Drive Engine

Z Pump76 kW
H Pump62-168 kW
D Pump180-228 kW
E Pump280-307 kW
G Pump236-602 kW
W Pump662-782 kW

Engine Model

Power/kW

01503004506007509001050
Emission Srandard:Euro ⅠEuro ⅡEuro ⅢEuro ⅣEuro ⅤEuro ⅥEuro Ⅶ
SDEC Pump Engine Catalogue
Series
Model

4ZTAA4.1-G21 | 76 kW @ 1800 RPM
SC4H95P2 | 62 kW @ 1800 RPMSC4H115D2 | 78 kW @ 1500 RPMSC4H115P2 | 78 kW @ 1800 RPMSC4H140D2 | 95 kW @ 1500 RPM
SC4H160D2 | 105 kW @ 1500 RPMSC4H160P2 | 105 kW @ 1800 RPMSC4H180P2 | 120 kW @ 1800 RPMSC7H230P2 | 154 kW @ 1800 RPM
SC7H250D2 | 168 kW @ 1500 RPMSC7H250P2 | 168 kW @ 1800 RPM4HTAA4.3-P21 | 105 kW @ 1800 RPM6HTAA6.5-P21 | 136 kW @ 1800 RPM
SC8D280P2 | 180 kW @ 1500 RPMSC9D310D2 | 208 kW @ 1500 RPMSC9D310P2 | 208 kW @ 1800 RPMSC9D340P2 | 228 kW @ 1800 RPM
SC12E420D2 | 280 kW @ 1500 RPMSC12E460D2 | 307 kW @ 1500 RPMSC12E460P2 | 307 kW @ 1800 RPM
SC13G355P2 | 236 kW @ 1800 RPMSC13G420P2 | 280 kW @ 1800 RPMSC15G500P2 | 330 kW @ 1800 RPMSC25G610P2 | 405 kW @ 1500 RPM
SC25G690P2 | 459 kW @ 1500 RPMSC27G755P2 | 505 kW @ 1500 RPMSC27G830P2 | 565 kW @ 1500 RPMSC27G900D2 | 602 kW @ 1500 RPM
SC27G900P2 | 602 kW @ 1500 RPM
SC33W990P2 | 662 kW @ 1500 RPMSC33W1150P2 | 782 kW @ 1500 RPM
——END——

SDEC SC9D340P2 Pump Drive Engine

SDEC SC9D340P2 Pump Drive Engine

Rated Power : 228 kW @ 1800 RPM
Emission Standard : TIER II
Number of Cylinders : 6
Engine Type : In-Line, 4 Strokes
Dry Weight : 900 Kg

SDEC SC9D310P2 Pump Drive Engine

SDEC SC9D310P2 Pump Drive Engine

Rated Power : 208 kW @ 1800 RPM
Emission Standard : TIER II
Number of Cylinders : 6
Engine Type : In-Line, 4 Strokes
Dry Weight : 740 Kg

SDEC SC9D310D2 Pump Drive Engine

SDEC SC9D310D2 Pump Drive Engine

Rated Power : 208 kW @ 1500 RPM
Displacement : 8.82 L
Number of Cylinders : 6
Engine Type : In-Line, 4 Strokes
Dry Weight : 740 Kg

SDEC SC8D280P2 Pump Drive Engine

SDEC SC8D280P2 Pump Drive Engine

Prime Power : 180 kW @ 1500 RPM
Emission Standard : TIER II
Number of Cylinders : 6
Engine Type : In-Line, 4 Strokes
Dry Weight : 740 Kg

SDEC SC12E460P2 Pump Drive Engine

SDEC SC12E460P2 Pump Drive Engine

Rated Power : 307 kW @ 1800 RPM
Emission Standard : TIER II
Number of Cylinders : 6
Engine Type : In-Line, 4 Strokes
Dry Weight : 1165 Kg

SDEC SC12E460D2 Pump Drive Engine

SDEC SC12E460D2 Pump Drive Engine

Rated Power : 307 kW @ 1500 RPM
Displacement : 11.8 L
Number of Cylinders : 6
Engine Type : In-Line, 4 Strokes
Dry Weight : 1070 Kg

SDEC SC12E420D2 Pump Drive Engine

SDEC SC12E420D2 Pump Drive Engine

Rated Power : 280 kW @ 1500 RPM
Displacement : 11.8 L
Number of Cylinders : 6
Engine Type : In-Line, 4 Strokes
Dry Weight : 1070 Kg

SDEC SC27G900P2 Pump Drive Engine

SDEC SC27G900P2 Pump Drive Engine

Rated Power : 602 kW @ 1500 RPM
Emission Standard : TIER II
Number of Cylinders : 12
Engine Type : V-Line, 4 Strokes
Dry Weight : 2250 Kg

SDEC SC27G900D2 Pump Drive Engine

SDEC SC27G900D2 Pump Drive Engine

Rated Power : 602 kW @ 1500 RPM
Displacement : 26.6 L
Number of Cylinders : 12
Engine Type : V-Line, 4 Strokes
Dry Weight : 2080 Kg

SDEC SC27G830P2 Pump Drive Engine

SDEC SC27G830P2 Pump Drive Engine

Rated Power : 565 kW @ 1500 RPM
Emission Standard : TIER II
Number of Cylinders : 12
Engine Type : V-Line, 4 Strokes
Dry Weight : 2250 Kg

SDEC SC27G755P2 Pump Drive Engine

SDEC SC27G755P2 Pump Drive Engine

Rated Power : 505 kW @ 1500 RPM
Emission Standard : TIER II
Number of Cylinders : 12
Engine Type : V-Line, 4 Strokes
Dry Weight : 2250 Kg

SDEC SC25G690P2 Pump Drive Engine

SDEC SC25G690P2 Pump Drive Engine

Rated Power : 459 kW @ 1500 RPM
Emission Standard : TIER II
Number of Cylinders : 12
Engine Type : V-Line, 4 Strokes
Dry Weight : 2250 Kg

SDEC SC25G610P2 Pump Drive Engine

SDEC SC25G610P2 Pump Drive Engine

Rated Power : 405 kW @ 1500 RPM
Emission Standard : TIER II
Number of Cylinders : 12
Engine Type : V-Line, 4 Strokes
Dry Weight : 2250 Kg

SDEC SC15G500P2 Pump Drive Engine

SDEC SC15G500P2 Pump Drive Engine

Rated Power : 330 kW @ 1800 RPM
Emission Standard : TIER II
Number of Cylinders : 6
Engine Type : In-Line, 4 Strokes
Dry Weight : 1290 Kg

SDEC SC13G420P2 Pump Drive Engine

SDEC SC13G420P2 Pump Drive Engine

Rated Power : 280 kW @ 1800 RPM
Emission Standard : TIER II
Number of Cylinders : 6
Engine Type : In-Line, 4 Strokes
Dry Weight : 1290 Kg

SDEC SC13G355P2 Pump Drive Engine

SDEC SC13G355P2 Pump Drive Engine

Rated Power : 236 kW @ 1800 RPM
Emission Standard : TIER II
Number of Cylinders : 6
Engine Type : In-Line, 4 Strokes
Dry Weight : 1290 Kg

SDEC SC7H250P2 Pump Drive Engine

SDEC SC7H250P2 Pump Drive Engine

Rated Power : 168 kW @ 1800 RPM
Emission Standard : TIER II
Number of Cylinders : 6
Engine Type : In-Line, 4 Strokes
Dry Weight : 600 Kg

SDEC SC7H250D2 Pump Drive Engine

SDEC SC7H250D2 Pump Drive Engine

Rated Power : 168 kW @ 1500 RPM
Displacement : 6.44 L
Number of Cylinders : 6
Engine Type : In-Line, 4 Strokes
Dry Weight : 600 Kg

SDEC SC7H230P2 Pump Drive Engine

SDEC SC7H230P2 Pump Drive Engine

Rated Power : 154 kW @ 1800 RPM
Emission Standard : TIER II
Number of Cylinders : 6
Engine Type : In-Line, 4 Strokes
Dry Weight : 600 Kg

SDEC SC4H180P2 Pump Drive Engine

SDEC SC4H180P2 Pump Drive Engine

Rated Power : 120 kW @ 1800 RPM
Emission Standard : TIER II
Number of Cylinders : 4
Engine Type : In-Line, 4 Strokes
Dry Weight : 460 Kg

SDEC SC4H160P2 Pump Drive Engine

SDEC SC4H160P2 Pump Drive Engine

Rated Power : 105 kW @ 1800 RPM
Emission Standard : TIER II
Number of Cylinders : 4
Engine Type : In-Line, 4 Strokes
Dry Weight : 460 Kg

SDEC SC4H160D2 Pump Drive Engine

SDEC SC4H160D2 Pump Drive Engine

Rated Power : 105 kW @ 1500 RPM
Displacement : 4.3 L
Number of Cylinders : 4
Engine Type : In-Line, 4 Strokes
Dry Weight : 450 Kg

SDEC SC4H140D2 Pump Drive Engine

SDEC SC4H140D2 Pump Drive Engine

Rated Power : 95 kW @ 1500 RPM
Displacement : 4.3 L
Number of Cylinders : 4
Engine Type : In-Line, 4 Strokes
Dry Weight : 450 Kg

SDEC SC4H115P2 Pump Drive Engine

SDEC SC4H115P2 Pump Drive Engine

Rated Power : 78 kW @ 1800 RPM
Emission Standard : TIER II
Number of Cylinders : 4
Engine Type : In-Line, 4 Strokes
Dry Weight : 430 Kg

SDEC SC4H115D2 Pump Drive Engine

SDEC SC4H115D2 Pump Drive Engine

Rated Power : 78 kW @ 1500 RPM
Displacement : 4.3 L
Number of Cylinders : 4
Engine Type : In-Line, 4 Strokes
Dry Weight : 450 Kg

SDEC SC4H95P2 Pump Drive Engine

SDEC SC4H95P2 Pump Drive Engine

Rated Power : 62 kW @ 1800 RPM
Emission Standard : TIER II
Number of Cylinders : 4
Engine Type : In-Line, 4 Strokes
Dry Weight : 430 Kg

SDEC SC33W1150P2 Pump Drive Engine

SDEC SC33W1150P2 Pump Drive Engine

Rated Power : 782 kW @ 1500 RPM
Emission Standard : TIER II
Number of Cylinders : 6
Engine Type : In-Line, 4 Strokes
Dry Weight : 3400 Kg

SDEC SC33W990P2 Pump Drive Engine

SDEC SC33W990P2 Pump Drive Engine

Rated Power : 662 kW @ 1500 RPM
Emission Standard : TIER II
Number of Cylinders : 6
Engine Type : In-Line, 4 Strokes
Dry Weight : 3400 Kg

SDEC 12KTA58-P31 Pump Drive Engine

SDEC 12KTA58-P31 Pump Drive Engine

Prime Power : 1986 kW @ 1500 RPM
Displacement : 57.2 L
Number of Cylinders : 12
Cylinder Type : Wet liner
Combustion Type : Direct injection

SDEC 12KTA58-P31 Pump Drive Engine

SDEC 12KTA58-P32 Pump Drive Engine

Prime Power : 1850 kW @ 1500 RPM
Displacement : 57.2 L
Number of Cylinders : 12
Cylinder Type : Wet liner
Combustion Type : Direct injection

SDEC 12KTA58-P31 Pump Drive Engine

SDEC 12KTA58-P33 Pump Drive Engine

Prime Power : 1720 kW @ 1500 RPM
Displacement : 57.2 L
Number of Cylinders : 12
Cylinder Type : Wet liner
Combustion Type : Direct injection

SDEC 12KTA58-P31 Pump Drive Engine

SDEC 12KTA58-P34 Pump Drive Engine

Prime Power : 1560 kW @ 1500 RPM
Displacement : 57.2 L
Number of Cylinders : 12
Cylinder Type : Wet liner
Combustion Type : Direct injection

SDEC 12KTA58-P31 Pump Drive Engine

SDEC 12KTA58-P35 Pump Drive Engine

Prime Power : 1420 kW @ 1500 RPM
Displacement : 57.2 L
Number of Cylinders : 12
Cylinder Type : Wet liner
Combustion Type : Direct injection

G-Drive Engine

D G Drive185-255 kW
E G Drive255-450 kW
G G Drive280-622 kW
H G Drive62-205 kW
K G Drive520-880 kW
R G Drive27-95 kW
W G Drive660-1118 kW
Z-T2 G Drive16-80 kW
Z-T3 G Drive12-74 kW
SR G Drive530-1800 kW

Engine Model

Power/kW

03006009001200150018002100
Emission Srandard:Euro ⅠEuro ⅡEuro ⅢEuro ⅣEuro ⅤEuro ⅥEuro Ⅶ
SDEC G-Drive Engine Catalogue
Series
Model

6DTAA8.9-G21 | 205 kW @ 1800 RPM 6DTAA8.9-G23 | 255 kW @ 1800 RPM 6DTAA8.9-G24 | 228 kW @ 1800 RPM 6DTAA8.9-G31 | 205 kW @ 1800 RPM
6DTAA8.9-G32 | 235 kW @ 1800 RPM6DTAA8.9-G33 | 255 kW @ 1800 RPM 6DTAA8.9-G34 | 255 kW @ 1800 RPM SC8D280D2 | 185 kW @ 1500 RPM
SC9D310D2 | 208 kW @ 1500 RPM SC9D340D2 | 228 kW @ 1500 RPM
6ETAA11.8-G21 | 307 kW @ 1800 RPM6ETAA11.8-G22 | 307 kW @ 1800 RPM 6ETAA11.8-G31 | 340 kW @ 1800 RPM6ETAA11.8-G32 | 307 kW @ 1800 RPM
6ETAA11.8-G33 | 340 kW @ 1800 RPM6ETAA12.8-G21 | 368 kW @ 1800 RPM6ETAA12.8-G22 | 368 kW @ 1800 RPM6ETAA12.8-G31 | 401 kW @ 1500 RPM
6ETAA12.8-G32 | 360 kW @ 1800 RPM 6ETAA12.8-G310.1 | 450 kW @ 1800 RPM6ETAA12.8-G310 | 450 kW @ 1500 RPMSC10E380D2 | 255 kW @ 1500 RPM
SC12E420D2 | 280 kW @ 1500 RPMSC12E460D2 | 307 kW @ 1500 RPMSC12E480D2 | 323 kW @ 1500 RPMSC13E500D2 | 339 kW @ 1500 RPM
SC13E520D2 | 348 kW @ 1500 RPMSC13E550D2 | 368 kW @ 1500 RPM
12GTAA27-G31 | 622 kW @ 1500 RPM12GTAA27-G32 | 565 kW @ 1500 RPM12GTAA27-G33 | 505 kW @ 1500 RPM12GTAA27-G34 | 459 kW @ 1500 RPM
SC13G420D2 | 280 kW @ 1500 RPMSC15G500D2 | 330 kW @ 1500 RPMSC25G610D2 | 405 kW @ 1500 RPMSC25G690D2 | 459 kW @ 1500 RPM
SC27G755D2 | 505 kW @ 1500 RPMSC27G830D2 | 561 kW @ 1500 RPMSC27G900D2 | 561 kW @ 1500 RPM
4HT4.3-G21 | 62 kW @ 1800 RPM4HT4.3-G22 | 67 kW @ 1800 RPM4HT4.3-G23 | 86 kW @ 1800 RPM4HTAA4.3-G21 | 105 kW @ 1800 RPM
4HTAA4.3-G22 | 120 kW @ 1800 RPM4HTAA4.3-G23 | 120 kW @ 1800 RPM4HTAA4.3-G31 | 62 kW @ 1800 RPM4HTAA4.3-G32 | 67 kW @ 1800 RPM
4HTAA4.3-G33 | 86 kW @ 1800 RPM4HTAA4.3-G34 | 105 kW @ 1800 RPM4HTAA4.3-G35 | 120 kW @ 1800 RPM4HTAA4.3-G36 | 125 kW @ 1800 RPM
6HTAA6.5-G21 | 136 kW @ 1800 RPM6HTAA6.5-G22 | 150 kW @ 1800 RPM6HTAA6.5-G23 | 180 kW @ 1800 RPM6HTAA6.5-G31 | 136 kW @ 1800 RPM
6HTAA6.5-G32 | 150 kW @ 1800 RPM6HTAA6.5-G33 | 180 kW @ 1800 RPM6HTAA6.5-G34 | 205 kW @ 1800 RPM6HTAA6.5-G35 | 170 kW @ 1800 RPM
SC4H95D2 | 62 kW @ 1500 RPMSC4H115D2 | 78 kW @ 1500 RPMSC4H140D2 | 95 kW @ 1500 RPMSC4H160D2 | 105 kW @ 1500 RPM
SC4H180D2 | 120 kW @ 1500 RPMSC7H180D2 | 120 kW @ 1500 RPMSC7H205D2 | 138 kW @ 1500 RPMSC7H220D2 | 150 kW @ 1500 RPM
SC7H230D2 | 154 kW @ 1500 RPMSC7H250D2 | 168 kW @ 1500 RPM
6KTAA25-G31.1 | 728 kW @ 1800 RPM6KTAA25-G31 | 728 kW @ 1500 RPM6KTAA25-G32 | 685 kW @ 1800 RPM6KTAA25-G33 | 622 kW @ 1800 RPM
6KTAA25-G34 | 622 kW @ 1800 RPM6KTAA25-G35 | 572 kW @ 1800 RPM6KTAA25-G36 | 520 kW @ 1800 RPM6KTAA25-G38 | 622 kW @ 1800 RPM
6KTAA25-G39 | 622 kW @ 1800 RPM6KTAA25-G310 | 572 kW @ 1800 RPM6KTAA25-G311 | 520 kW @ 1800 RPM6KTAA25-G320 | 820 kW @ 1500 RPM
6KTAA25-G321 | 880 kW @ 1500 RPM
4RTAA2.8-G31 | 38 kW @ 1500 RPM4RTAA2.8-G32 | 51 kW @ 1500 RPM4RTAA2.8-G34 | 62 kW @ 3000 RPM4RTAA2.8-G35 | 80 kW @ 3000 RPM
4RTAA2.8-G37 | 62 kW @ 1500 RPM4RTAA2.8-G38 | 95 kW @ 3000 RPM4RTAA2.8-G39 | 27 kW @ 1500 RPM
6WTAA35-G31 | 882 kW @ 1500 RPM6WTAA35-G32 | 818 kW @ 1500 RPM6WTAA35-G310 | 1018 kW @ 1500 RPM6WTAA35-G311 | 1118 kW @ 1500 RPM
SC33W990D2 | 660 kW @ 1500 RPMSC33W1150D2 | 782 kW @ 1500 RPM
4Z2.3-G11 | 16 kW @ 1500 RPM4Z2.3-G12 | 21 kW @ 1800 RPM4Z2.3-G21 | 21 kW @ 1800 RPM4Z2.7-G11 | 22 kW @ 1500 RPM
4Z2.7-G12 | 26 kW @ 1800 RPM4Z2.7-G21 | 26 kW @ 1800 RPM4Z3.0-G11 | 27 kW @ 1500 RPM4Z3.0-G12 | 30 kW @ 1800 RPM
4Z3.0-G21 | 30 kW @ 1800 RPM4Z3.2-G11 | 32 kW @ 1500 RPM4Z3.2-G12 | 38 kW @ 1800 RPM4Z3.2-G21 | 38 kW @ 1800 RPM
4ZT3.2-G11 | 39 kW @ 1500 RPM4ZT3.2-G12 | 42 kW @ 1800 RPM4ZT3.2-G21 | 42 kW @ 1800 RPM4ZT3.5-G21 | 60 kW @ 1800 RPM
4ZT4.1-G21 | 70 kW @ 1800 RPM4ZTAA4.1-G21 | 76 kW @ 1800 RPM4ZTAA4.1-G31 | 80 kW @ 1800 RPM
3Z1.1-G41 | 16.8 kW @ 3000 RPM3Z1.1-G42 | 12 kW @ 1800 RPM3ZT1.1-G41 | 25 kW @ 3000 RPM3ZT1.1-G42 | 15.5 kW @ 1800 RPM
4Z2.9-G41 | 30 kW @ 1800 RPM4Z2.9-G42 | 26 kW @ 1800 RPM4Z2.9-G43 | 21 kW @ 1800 RPM4Z2.9-G410 | 30 kW @ 1800 RPM
4Z2.9-G420 | 26 kW @ 1800 RPM4Z2.9-G430 | 21 kW @ 1800 RPM4Z3.2-G41 | 21 kW @ 1800 RPM4Z3.2-G42 | 36 kW @ 1800 RPM
4ZTAA3.2-G31 | 70 kW @ 1800 RPM4ZTAA3.2-G32 | 60 kW @ 1800 RPM4ZTAA3.2-G33 | 49 kW @ 1800 RPM4ZTAA3.2-G34 | 64 kW @1800 RPM
4ZTAA3.5-G31 | 74 kW @ 1800 RPM
S6R2-PTAA-C | 600 kW @ 1500 RPMS6R2-PTA-C | 530 kW @ 1500 RPMS12R-PTA2-C | 1100 kW @ 1500 RPMS12R-PTAA2-C | 1200 kW @ 1500 RPM
S12R-PTA-C | 1000 kW @ 1500 RPMS16R2-PTAW-C | 1800 kW @ 1500 RPMS16R-PTA2-C | 1500 kW @ 1500 RPMS16R2-PTAA2-C | 1600 kW @ 1500 RPM
——END——

SDEC 6DTAA8.9-G21 G-Drive Engine

SDEC 6DTAA8.9-G21 G-Drive Engine

Rated Power: 205 kW @ 1800 RPM
Displacement : 8.82 L
Number of Cylinders : 6
Cylinder Type : Wet Liner
Combustion Type : Direct Injection

SDEC 6DTAA8.9-G23 G-Drive Engine

SDEC 6DTAA8.9-G23 G-Drive Engine

Prime Power: 255 kW @ 1800 RPM
Displacement : 8.82 L
Number of Cylinders : 6
Cylinder Type : Wet Liner
Combustion Type : Direct Injection

SDEC 6DTAA8.9-G24 G-Drive Engine

SDEC 6DTAA8.9-G24 G-Drive Engine

Prime Power: 228 kW @ 1800 RPM
Displacement : 8.82 L
Number of Cylinders : 6
Cylinder Type : Wet Liner
Combustion Type : Direct Injection

SDEC 6DTAA8.9-G31 G-Drive Engine

SDEC 6DTAA8.9-G31 G-Drive Engine

Prime Power: 205 kW @ 1800 RPM
Displacement : 8.82 L
Number of Cylinders : 6
Cylinder Type : Wet Liner
Combustion Type : Direct Injection

SDEC 6DTAA8.9-G32 G-Drive Engine

SDEC 6DTAA8.9-G32 G-Drive Engine

Prime Power: 235 kW @ 1800 RPM
Displacement : 8.82 L
Number of Cylinders : 6
Cylinder Type : Wet Liner
Combustion Type : Direct Injection

SDEC 6DTAA8.9-G33 G-Drive Engine

SDEC 6DTAA8.9-G33 G-Drive Engine

Prime Power: 255 kW @ 1800 RPM
Displacement : 8.82 L
Number of Cylinders : 6
Cylinder Type : Wet Liner
Combustion Type : Direct Injection

SDEC 6DTAA8.9-G34 G-Drive Engine

SDEC 6DTAA8.9-G34 G-Drive Engine

Prime Power: 255 kW @ 1800 RPM
Displacement : 8.82 L
Number of Cylinders : 6
Cylinder Type : Wet Liner
Combustion Type : Direct Injection

SDEC SC8D280D2 G-Drive Engine

SDEC SC8D280D2 G-Drive Engine

Prime Power: 185 kW @ 1500 RPM
Displacement : 8.27 L
Number of Cylinders : 6
Cylinder Type : Wet Liner
Combustion Type : Direct Injection

SDEC SC9D310D2 G-Drive Engine

SDEC SC9D310D2 G-Drive Engine

Prime Power: 208 kW @ 1500 RPM
Displacement : 8.82 L
Number of Cylinders : 6
Cylinder Type : Wet Liner
Combustion Type : Direct Injection

SDEC SC9D340D2 G-Drive Engine

SDEC SC9D340D2 G-Drive Engine

Prime Power: 208 kW @ 1500 RPM
Displacement : 8.82 L
Number of Cylinders : 6
Cylinder Type : Wet Liner
Combustion Type : Direct Injection

SDEC 6ETAA11.8-G21 G-Drive Engine

SDEC 6ETAA11.8-G21 G-Drive Engine

Prime Power : 307 kW @ 1800 RPM
Displacement : 11.8 L
Number of Cylinders : 6
Cylinder Type : Dry liner
Combustion Type : Direct injection

SDEC 6ETAA11.8-G22 G-Drive Engine

SDEC 6ETAA11.8-G22 G-Drive Engine

Prime Power : 307 kW @ 1800RPM
Displacement : 11.8 L
Number of Cylinders : 6
Cylinder Type : Dry liner
Combustion Type : Direct injection

SDEC 6ETAA11.8-G31 G-Drive Engine

SDEC 6ETAA11.8-G31 G-Drive Engine

Prime Power : 340 kW @ 1800 RPM
Displacement : 11.8 L
Number of Cylinders : 6
Cylinder Type : Dry liner
Combustion Type : Direct injection

SDEC 6ETAA11.8-G32 G-Drive Engine

SDEC 6ETAA11.8-G32 G-Drive Engine

Prime Power : 307 kW @ 1800 RPM
Displacement : 11.8 L
Number of Cylinders : 6
Cylinder Type : Dry liner
Combustion Type : Direct injection

SDEC 6ETAA11.8-G33 G-Drive Engine

SDEC 6ETAA11.8-G33 G-Drive Engine

Prime Power : 340 kW @ 1800 RPM
Displacement : 11.8 L
Number of Cylinders : 6
Cylinder Type : Dry liner
Combustion Type : Direct injection

SDEC 6ETAA12.8-G21 G-Drive Engine

SDEC 6ETAA12.8-G21 G-Drive Engine

Prime Power : 368 kW @ 1800 RPM
Displacement : 12.8 L
Number of Cylinders : 6
Cylinder Type : Dry liner
Combustion Type : Direct injection

SDEC 6ETAA12.8-G22 G-Drive Engine

SDEC 6ETAA12.8-G22 G-Drive Engine

Prime Power : 368 kW @ 1800 RPM
Displacement : 12.8 L
Number of Cylinders : 6
Cylinder Type : Dry liner
Combustion Type : Direct injection

SDEC 6ETAA12.8-G31 G-Drive Engine

SDEC 6ETAA12.8-G31 G-Drive Engine

Prime Power : 401 kW @ 1500 RPM
Displacement : 12.8 L
Number of Cylinders : 6
Cylinder Type : Dry liner
Combustion Type : Direct injection

SDEC 6ETAA12.8-G32 G-Drive Engine

SDEC 6ETAA12.8-G32 G-Drive Engine

Prime Power : 360 kW @ 1800 RPM
Displacement : 12.8 L
Number of Cylinders : 6
Cylinder Type : Dry liner
Combustion Type : Direct injection

SDEC 6ETAA12.8-G310 G-Drive Engine

SDEC 6ETAA12.8-G310 G-Drive Engine

Prime Power : 450 kW @ 1500 RPM
Displacement : 12.8 L
Number of Cylinders : 6
Cylinder Type : Dry liner
Combustion Type : Direct injection

SDEC SC10E380D2 G-Drive Engine

SDEC SC10E380D2 G-Drive Engine

Prime Power : 255 kW @ 1500 RPM
Displacement : 10.8 L
Number of Cylinders : 6
Cylinder Type : Dry liner
Combustion Type : Direct injection

SDEC SC12E420D2 G-Drive Engine

SDEC SC12E420D2 G-Drive Engine

Prime Power : 280 kW @ 1500 RPM
Displacement : 11.8 L
Number of Cylinders : 6
Cylinder Type : Dry liner
Combustion Type : Direct injection

SDEC SC12E460D2 G-Drive Engine

SDEC SC12E460D2 G-Drive Engine

Prime Power : 307 kW @ 1500 RPM
Displacement : 11.8 L
Number of Cylinders : 6
Cylinder Type : Dry liner
Combustion Type : Direct injection

SDEC SC12E480D2 G-Drive Engine

SDEC SC12E480D2 G-Drive Engine

Prime Power : 323 kW @ 1500 RPM
Displacement : 11.8 L
Number of Cylinders : 6
Cylinder Type : Dry liner
Combustion Type : Direct injection

SDEC SC13E500D2 G-Drive Engine

SDEC SC13E500D2 G-Drive Engine

Prime Power : 339 kW @ 1500 RPM
Displacement : 12.8 L
Number of Cylinders : 6
Cylinder Type : Dry liner
Combustion Type : Direct injection

SDEC SC13E520D2 G-Drive Engine

SDEC SC13E520D2 G-Drive Engine

Prime Power : 348 kW @ 1500 RPM
Displacement : 12.8 L
Number of Cylinders : 6
Cylinder Type : Dry liner
Combustion Type : Direct injection

SDEC SC13E550D2 G-Drive Engine

SDEC SC13E550D2 G-Drive Engine

Prime Power : 368 kW @ 1500 RPM
Displacement : 12.8 L
Number of Cylinders : 6
Cylinder Type : Dry liner
Combustion Type : Direct injection

SDEC 12GTAA27-G31 G-Drive Engine

SDEC 12GTAA27-G31 G-Drive Engine

Rated Power: 622 kW @ 1500 RPM
Displacement : 26.6 L
Number of Cylinders : 12
Cylinder Type : Dry Liner
Combustion Type : Direct Injection

SDEC 12GTAA27-G32 G-Drive Engine

SDEC 12GTAA27-G32 G-Drive Engine

Rated Power: 565 kW @ 1500 RPM
Displacement : 26.6 L
Number of Cylinders : 12
Cylinder Type : Dry Liner
Combustion Type : Direct Injection

SDEC 12GTAA27-G33 G-Drive Engine

SDEC 12GTAA27-G33 G-Drive Engine

Rated Power: 505 kW @ 1500 RPM
Displacement : 26.6 L
Number of Cylinders : 12
Cylinder Type : Dry Liner
Combustion Type : Direct Injection

SDEC 12GTAA27-G34 G-Drive Engine

SDEC 12GTAA27-G34 G-Drive Engine

Rated Power: 459 kW @ 1500 RPM
Displacement : 26.6 L
Number of Cylinders : 12
Cylinder Type : Dry Liner
Combustion Type : Direct Injection

SDEC SC13G420D2 G-Drive Engine

SDEC SC13G420D2 G-Drive Engine

Rated Power: 280 kW @ 1500 RPM
Displacement : 12.88 L
Number of Cylinders : 6
Cylinder Type : Dry Liner
Combustion Type : Direct Injection

SDEC SC15G500D2 G-Drive Engine

SDEC SC15G500D2 G-Drive Engine

Rated Power: 330 kW @ 1500 RPM
Displacement : 12.88 L
Number of Cylinders : 6
Cylinder Type : Dry Liner
Combustion Type : Direct Injection

SDEC SC25G610D2 G-Drive Engine

SDEC SC25G610D2 G-Drive Engine

Rated Power: 405 kW @ 1500 RPM
Displacement : 25.8 L
Number of Cylinders : 12
Cylinder Type : Dry Liner
Combustion Type : Direct Injection

SDEC SC25G690D2 G-Drive Engine

SDEC SC25G690D2 G-Drive Engine

Rated Power: 459 kW @ 1500 RPM
Displacement : 25.8 L
Number of Cylinders : 12
Cylinder Type : Dry Liner
Combustion Type : Direct Injection

SDEC SC27G755D2 G-Drive Engine

SDEC SC27G755D2 G-Drive Engine

Rated Power: 505 kW @ 1500 RPM
Displacement : 26.6 L
Number of Cylinders : 12
Cylinder Type : Dry Liner
Combustion Type : Direct Injection

SDEC SC27G830D2 G-Drive Engine

SDEC SC27G830D2 G-Drive Engine

Rated Power: 561 kW @ 1500 RPM
Displacement : 26.6 L
Number of Cylinders : 12
Cylinder Type : Dry Liner
Combustion Type : Direct Injection

SDEC SC27G900D2 G-Drive Engine

SDEC SC27G900D2 G-Drive Engine

Rated Power: 561 kW @ 1500 RPM
Displacement : 26.6 L
Number of Cylinders : 12
Cylinder Type : Dry Liner
Combustion Type : Direct Injection

SDEC 4HT4.3-G21 G-Drive Engine

SDEC 4HT4.3-G21 G-Drive Engine

Prime Power : 62 kW @ 1800 RPM
Displacement : 4.3 L
Number of Cylinders : 4
Cylinder Type : Dry Liner
Combustion Type : Direct Injection

SDEC 4HT4.3-G22 G-Drive Engine

SDEC 4HT4.3-G22 G-Drive Engine

Prime Power : 67 kW @ 1800 RPM
Displacement : 4.3 L
Number of Cylinders : 4
Cylinder Type : Dry Liner
Combustion Type : Direct Injection

SDEC 4HT4.3-G23 G-Drive Engine

SDEC 4HT4.3-G23 G-Drive Engine

Prime Power : 86 kW @ 1800 RPM
Displacement : 4.3 L
Number of Cylinders : 4
Cylinder Type : Dry Liner
Combustion Type : Direct Injection

SDEC 4HTAA4.3-G21 G-Drive Engine

SDEC 4HTAA4.3-G21 G-Drive Engine

Prime Power : 105 kW @ 1800 RPM
Displacement : 4.3 L
Number of Cylinders : 4
Cylinder Type : Dry Liner
Combustion Type : Direct Injection

SDEC 4HTAA4.3-G22 G-Drive Engine

SDEC 4HTAA4.3-G22 G-Drive Engine

Prime Power : 120 kW @ 1800 RPM
Displacement : 4.3 L
Number of Cylinders : 4
Cylinder Type : Dry Liner
Combustion Type : Direct Injection

SDEC 4HTAA4.3-G23 G-Drive Engine

SDEC 4HTAA4.3-G23 G-Drive Engine

Prime Power : 120 kW @ 1800 RPM
Displacement : 4.3 L
Number of Cylinders : 4
Cylinder Type : Dry Liner
Combustion Type : Direct Injection

SDEC 4HTAA4.3-G31 G-Drive Engine

SDEC 4HTAA4.3-G31 G-Drive Engine

Prime Power : 62 kW @ 1800 RPM
Displacement : 4.3 L
Number of Cylinders : 4
Cylinder Type : Dry Liner
Combustion Type : Direct Injection

SDEC 4HTAA4.3-G32 G-Drive Engine

SDEC 4HTAA4.3-G32 G-Drive Engine

Prime Power : 67 kW @ 1800 RPM
Displacement : 4.3 L
Number of Cylinders : 4
Cylinder Type : Dry Liner
Combustion Type : Direct Injection

SDEC 4HTAA4.3-G33 G-Drive Engine

SDEC 4HTAA4.3-G33 G-Drive Engine

Prime Power : 86 kW @ 1800 RPM
Displacement : 4.3 L
Number of Cylinders : 4
Cylinder Type : Dry Liner
Combustion Type : Direct Injection

SDEC 4HTAA4.3-G34 G-Drive Engine

SDEC 4HTAA4.3-G34 G-Drive Engine

Prime Power : 105 kW @ 1800 RPM
Displacement : 4.3 L
Number of Cylinders : 4
Cylinder Type : Dry Liner
Combustion Type : Direct Injection

SDEC 4HTAA4.3-G35 G-Drive Engine

SDEC 4HTAA4.3-G35 G-Drive Engine

Prime Power : 120 kW @ 1800 RPM
Displacement : 4.3 L
Number of Cylinders : 4
Cylinder Type : Dry Liner
Combustion Type : Direct Injection

SDEC 4HTAA4.3-G36 G-Drive Engine

SDEC 4HTAA4.3-G36 G-Drive Engine

Prime Power : 125 kW @ 1800 RPM
Displacement : 4.3 L
Number of Cylinders : 4
Cylinder Type : Dry Liner
Combustion Type : Direct Injection

SDEC 6HTAA6.5-G21 G-Drive Engine

SDEC 6HTAA6.5-G21 G-Drive Engine

Prime Power : 136 kW @ 1800 RPM
Displacement : 6.5 L
Number of Cylinders : 6
Cylinder Type : Dry Liner
Combustion Type : Direct Injection

SDEC 6HTAA6.5-G22 G-Drive Engine

SDEC 6HTAA6.5-G22 G-Drive Engine

Prime Power : 150 kW @ 1800 RPM
Displacement : 6.5 L
Number of Cylinders : 6
Cylinder Type : Dry Liner
Combustion Type : Direct Injection

SDEC 6HTAA6.5-G23 G-Drive Engine

SDEC 6HTAA6.5-G23 G-Drive Engine

Prime Power : 180 kW @ 1800 RPM
Displacement : 6.5 L
Number of Cylinders : 6
Cylinder Type : Dry Liner
Combustion Type : Direct Injection

SDEC 6HTAA6.5-G31 G-Drive Engine

SDEC 6HTAA6.5-G31 G-Drive Engine

Prime Power : 136 kW @ 1800 RPM
Displacement : 6.5 L
Number of Cylinders : 6
Cylinder Type : Dry Liner
Combustion Type : Direct Injection

SDEC 6HTAA6.5-G32 G-Drive Engine

SDEC 6HTAA6.5-G32 G-Drive Engine

Prime Power : 150 kW @ 1800 RPM
Displacement : 6.5 L
Number of Cylinders : 6
Cylinder Type : Dry Liner
Combustion Type : Direct Injection

SDEC 6HTAA6.5-G33 G-Drive Engine

SDEC 6HTAA6.5-G33 G-Drive Engine

Prime Power : 180 kW @ 1800 RPM
Displacement : 6.5 L
Number of Cylinders : 6
Cylinder Type : Dry Liner
Combustion Type : Direct Injection

SDEC 6HTAA6.5-G34 G-Drive Engine

SDEC 6HTAA6.5-G34 G-Drive Engine

Prime Power : 205 kW @ 1800 RPM
Displacement : 6.5 L
Number of Cylinders : 6
Cylinder Type : Dry Liner
Combustion Type : Direct Injection

SDEC 6HTAA6.5-G35 G-Drive Engine

SDEC 6HTAA6.5-G35 G-Drive Engine

Prime Power : 170 kW @ 1800 RPM
Displacement : 6.5 L
Number of Cylinders : 6
Cylinder Type : Dry Liner
Combustion Type : Direct Injection

SDEC SC4H115D2 G-Drive Engine

SDEC SC4H115D2 G-Drive Engine

Prime Power : 78 kW @ 1500 RPM
Displacement : 4.3 L
Number of Cylinders : 4
Cylinder Type : Dry Liner
Combustion Type : Direct Injection

SDEC SC4H140D2 G-Drive Engine

SDEC SC4H140D2 G-Drive Engine

Prime Power : 95 kW @ 1500 RPM
Displacement : 4.3 L
Number of Cylinders : 4
Cylinder Type : Dry Liner
Combustion Type : Direct Injection

SDEC SC4H160D2 G-Drive Engine

SDEC SC4H160D2 G-Drive Engine

Prime Power : 105 kW @ 1500 RPM
Displacement : 4.3 L
Number of Cylinders : 4
Cylinder Type : Dry Liner
Combustion Type : Direct Injection

SDEC SC4H180D2 G-Drive Engine

SDEC SC4H180D2 G-Drive Engine

Prime Power : 120 kW @ 1500 RPM
Displacement : 4.3 L
Number of Cylinders : 4
Cylinder Type : Dry Liner
Combustion Type : Direct Injection

SDEC SC4H95D2 G-Drive Engine

SDEC SC4H95D2 G-Drive Engine

Prime Power : 62 kW @ 1500 RPM
Displacement : 4.3 L
Number of Cylinders : 4
Cylinder Type : Dry Liner
Combustion Type : Direct Injection

SDEC SC7H180D2 G-Drive Engine

SDEC SC7H180D2 G-Drive Engine

Prime Power : 120 kW @ 1500 RPM
Displacement : 6.44 L
Number of Cylinders : 6
Cylinder Type : Dry Liner
Combustion Type : Direct Injection

SDEC SC7H205D2 G-Drive Engine

SDEC SC7H205D2 G-Drive Engine

Prime Power : 138 kW @ 1500 RPM
Displacement : 6.44 L
Number of Cylinders : 6
Cylinder Type : Dry Liner
Combustion Type : Direct Injection

SDEC SC7H220D2 G-Drive Engine

SDEC SC7H220D2 G-Drive Engine

Prime Power : 150 kW @ 1500 RPM
Displacement : 6.44 L
Number of Cylinders : 6
Cylinder Type : Dry Liner
Combustion Type : Direct Injection

SDEC SC7H230D2 G-Drive Engine

SDEC SC7H230D2 G-Drive Engine

Prime Power : 154 kW @ 1500 RPM
Displacement : 6.44 L
Number of Cylinders : 6
Cylinder Type : Dry Liner
Combustion Type : Direct Injection

SDEC SC7H250D2 G-Drive Engine

SDEC SC7H250D2 G-Drive Engine

Prime Power : 168 kW @ 1500 RPM
Displacement : 6.44 L
Number of Cylinders : 6
Cylinder Type : Dry Liner
Combustion Type : Direct Injection

SDEC 6KTAA25-G31.1 G-Drive Engine

SDEC 6KTAA25-G31.1 G-Drive Engine

Prime Power : 728 kW @ 1800 RPM
Displacement : 25.2 L
Number of Cylinders : 6
Cylinder Type : Dry liner
Combustion Type : Direct injection

SDEC 6KTAA25-G31 G-Drive Engine

SDEC 6KTAA25-G31 G-Drive Engine

Prime Power : 728 kW @ 1500 RPM
Displacement : 25.2 L
Number of Cylinders : 6
Cylinder Type : Dry liner
Combustion Type : Direct injection

SDEC 6KTAA25-G32 G-Drive Engine

SDEC 6KTAA25-G32 G-Drive Engine

Prime Power : 685 kW @ 1800 RPM
Displacement : 25.2 L
Number of Cylinders : 6
Cylinder Type : Dry liner
Combustion Type : Direct injectionn

SDEC 6KTAA25-G33 G-Drive Engine

SDEC 6KTAA25-G33 G-Drive Engine

Prime Power : 622 kW @ 1800 RPM
Displacement : 25.2 L
Number of Cylinders : 6
Cylinder Type : Dry liner
Combustion Type : Direct injection

SDEC 6KTAA25-G34 G-Drive Engine

SDEC 6KTAA25-G34 G-Drive Engine

Prime Power : 622 kW @ 1800 RPM
Displacement : 25.2 L
Number of Cylinders : 6
Cylinder Type : Dry liner
Combustion Type : Direct injection

SDEC 6KTAA25-G35 G-Drive Engine

SDEC 6KTAA25-G35 G-Drive Engine

Prime Power : 572 kW @ 1800 RPM
Displacement : 25.2 L
Number of Cylinders : 6
Cylinder Type : Dry liner
Combustion Type : Direct injection

SDEC 6KTAA25-G36 G-Drive Engine

SDEC 6KTAA25-G36 G-Drive Engine

Prime Power : 520 kW @ 1800 RPM
Displacement : 25.2 L
Number of Cylinders : 6
Cylinder Type : Dry liner
Combustion Type : Direct injection

SDEC 6KTAA25-G38 G-Drive Engine

SDEC 6KTAA25-G38 G-Drive Engine

Prime Power : 622 kW @ 1800 RPM
Displacement : 25.2 L
Number of Cylinders : 6
Cylinder Type : Dry liner
Combustion Type : Direct injection

SDEC 6KTAA25-G39 G-Drive Engine

SDEC 6KTAA25-G39 G-Drive Engine

Prime Power : 622 kW @ 1800 RPM
Displacement : 25.2 L
Number of Cylinders : 6
Cylinder Type : Dry liner
Combustion Type : Direct injection

SDEC 6KTAA25-G310 G-Drive Engine

SDEC 6KTAA25-G310 G-Drive Engine

Prime Power : 572 kW @ 1800 RPM
Displacement : 25.2 L
Number of Cylinders : 6
Cylinder Type : Dry liner
Combustion Type : Direct injection

SDEC 6KTAA25-G311 G-Drive Engine

SDEC 6KTAA25-G311 G-Drive Engine

Prime Power : 520 kW @ 1800 RPM
Displacement : 25.2 L
Number of Cylinders : 6
Cylinder Type : Dry liner
Combustion Type : Direct injection

SDEC 6KTAA25-G320 G-Drive Engine

SDEC 6KTAA25-G320 G-Drive Engine

Prime Power : 820 kW @ 1500 RPM
Displacement : 25.2 L
Number of Cylinders : 6
Cylinder Type : Dry liner
Combustion Type : Direct injection

SDEC 6KTAA25-G321 G-Drive Engine

SDEC 6KTAA25-G321 G-Drive Engine

Prime Power : 880 kW @ 1500 RPM
Displacement : 25.2 L
Number of Cylinders : 6
Cylinder Type : Dry liner
Combustion Type : Direct injection

SDEC 4RTAA2.8-G31 G-Drive Engine

Prime Power : 38 kW @ 1500 RPM
Displacement : 2.8 L
Number of Cylinders : 4
Cylinder Type : Dry liner
Combustion Type : Direct injection

SDEC 4RTAA2.8-G32 G-Drive Engine

Prime Power : 51 kW @ 1500 RPM
Displacement : 2.8 L
Number of Cylinders : 4
Cylinder Type : Dry liner
Combustion Type : Direct injection

SDEC 4RTAA2.8-G34 G-Drive Engine

Prime Power : 62 kW @ 3000 RPM
Displacement : 2.8 L
Number of Cylinders : 4
Cylinder Type : Dry liner
Combustion Type : Direct injection

SDEC 4RTAA2.8-G35 G-Drive Engine

Prime Power : 80 kW @ 3000 RPM
Displacement : 2.8 L
Number of Cylinders : 4
Cylinder Type : Dry liner
Combustion Type : Direct injection

SDEC 4RTAA2.8-G37 G-Drive Engine

Prime Power : 62 kW @ 1500 RPM
Displacement : 2.8 L
Number of Cylinders : 4
Cylinder Type : Dry liner
Combustion Type : Direct injection

SDEC 4RTAA2.8-G38 G-Drive Engine

Prime Power : 95 kW @ 3000 RPM
Displacement : 2.8 L
Number of Cylinders : 4
Cylinder Type : Dry liner
Combustion Type : Direct injection

SDEC 4RTAA2.8-G39 G-Drive Engine

Prime Power : 27 kW @ 1500 RPM
Displacement : 2.8 L
Number of Cylinders : 4
Cylinder Type : Dry liner
Combustion Type : Direct injection

SDEC 6WTAA35-G31 G-Drive Engine

SDEC 6WTAA35-G31 G-Drive Engine

Prime Power : 882 kW @ 1500 RPM
Displacement : 35.1 L
Number of Cylinders : 6
Cylinder Type : Dry Liner
Combustion Type : Direct Injection

SDEC 6WTAA35-G32 G-Drive Engine

SDEC 6WTAA35-G32 G-Drive Engine

Prime Power : 818 kW @ 1500 RPM
Displacement : 35.1 L
Number of Cylinders : 6
Cylinder Type : Dry Liner
Combustion Type : Direct Injection

SDEC 6WTAA35-G310 G-Drive Engine

SDEC 6WTAA35-G310 G-Drive Engine

Prime Power : 1018 kW @ 1500 RPM
Displacement : 35.1 L
Number of Cylinders : 6
Cylinder Type : Dry Liner
Combustion Type : Direct Injection

SDEC 6WTAA35-G311 G-Drive Engine

SDEC 6WTAA35-G311 G-Drive Engine

Prime Power : 1118 kW @ 1500 RPM
Displacement : 35.1 L
Number of Cylinders : 6
Cylinder Type : Dry Liner
Combustion Type : Direct Injection

SDEC SC33W990D2 G-Drive Engine

SDEC SC33W990D2 G-Drive Engine

Prime Power : 660 kW @ 1500 RPM
Displacement : 32.8 L
Number of Cylinders : 6
Cylinder Type : Dry Liner
Combustion Type : Direct Injection

SDEC SC33W1150D2 G-Drive Engine

SDEC SC33W1150D2 G-Drive Engine

Prime Power : 782 kW @ 1500 RPM
Displacement : 32.8 L
Number of Cylinders : 6
Cylinder Type : Dry Liner
Combustion Type : Direct Injection

SDEC SC9D340P2 Pump Drive Engine

SDEC SC9D340P2 Pump Drive Engine

Rated Power : 228 kW @ 1800 RPM
Emission Standard : TIER II
Number of Cylinders : 6
Engine Type : In-Line, 4 Strokes
Dry Weight : 900 Kg

SDEC SC9D310P2 Pump Drive Engine

SDEC SC9D310P2 Pump Drive Engine

Rated Power : 208 kW @ 1800 RPM
Emission Standard : TIER II
Number of Cylinders : 6
Engine Type : In-Line, 4 Strokes
Dry Weight : 740 Kg

SDEC SC9D310D2 Pump Drive Engine

SDEC SC9D310D2 Pump Drive Engine

Rated Power : 208 kW @ 1500 RPM
Displacement : 8.82 L
Number of Cylinders : 6
Engine Type : In-Line, 4 Strokes
Dry Weight : 740 Kg

SDEC SC8D280P2 Pump Drive Engine

SDEC SC8D280P2 Pump Drive Engine

Prime Power : 180 kW @ 1500 RPM
Emission Standard : TIER II
Number of Cylinders : 6
Engine Type : In-Line, 4 Strokes
Dry Weight : 740 Kg

SDEC 4Z2.3-G11 G-Drive Engine

Prime Power : 16 kW @ 1500 RPM
Displacement : 2.3 L
Number of Cylinders : 4
Cylinder Type : Wet Liner
Combustion Type : Direct Injection

SDEC 4Z2.3-G12 G-Drive Engine

Prime Power : 21 kW @ 1800 RPM
Displacement : 2.3 L
Number of Cylinders : 4
Cylinder Type : Wet Liner
Combustion Type : Direct Injection

SDEC 4Z2.3-G21 G-Drive Engine

Prime Power : 21 kW @ 1800 RPM
Displacement : 2.3 L
Number of Cylinders : 4
Cylinder Type : Wet Liner
Combustion Type : Direct Injection

SDEC 4Z2.7-G11 G-Drive Engine

Prime Power : 22 kW @ 1500 RPM
Displacement : 2.7 L
Number of Cylinders : 4
Cylinder Type : Wet Liner
Combustion Type : Direct Injection

SDEC 4Z2.7-G12 G-Drive Engine

Prime Power : 26 kW @ 1800 RPM
Displacement : 2.7 L
Number of Cylinders : 4
Cylinder Type : Wet Liner
Combustion Type : Direct Injection

SDEC 4Z2.7-G21 G-Drive Engine

Prime Power : 26 kW @ 1800 RPM
Displacement : 2.7 L
Number of Cylinders : 4
Cylinder Type : Wet Liner
Combustion Type : Direct Injection

SDEC 4Z3.0-G11 G-Drive Engine

Prime Power : 27 kW @ 1500 RPM
Displacement : 3.0 L
Number of Cylinders : 4
Cylinder Type : Wet Liner
Combustion Type : Direct Injection

SDEC 4Z3.0-G12 G-Drive Engine

Prime Power : 30 kW @ 1800 RPM
Displacement : 3.0 L
Number of Cylinders : 4
Cylinder Type : Wet Liner
Combustion Type : Direct Injection

SDEC 4Z3.0-G21 G-Drive Engine

Prime Power : 30 kW @ 1800 RPM
Displacement : 3.0 L
Number of Cylinders : 4
Cylinder Type : Wet Liner
Combustion Type : Direct Injection

SDEC 4Z3.2-G11 G-Drive Engine

Prime Power : 32 kW @ 1500 RPM
Displacement : 3.2 L
Number of Cylinders : 4
Cylinder Type : Wet Liner
Combustion Type : Direct Injection

SDEC 4Z3.2-G12 G-Drive Engine

Prime Power : 38 kW @ 1800 RPM
Displacement : 3.2 L
Number of Cylinders : 4
Cylinder Type : Wet Liner
Combustion Type : Direct Injection

SDEC 4Z3.2-G21 G-Drive Engine

Prime Power : 38 kW @ 1800 RPM
Displacement : 3.2 L
Number of Cylinders : 4
Cylinder Type : Wet Liner
Combustion Type : Direct Injection

SDEC 4ZT3.2-G11 G-Drive Engine

Prime Power : 39 kW @ 1500 RPM
Displacement : 3.2 L
Number of Cylinders : 4
Cylinder Type : Wet Liner
Combustion Type : Direct Injection

SDEC 4ZT3.2-G12 G-Drive Engine

Prime Power : 42 kW @ 1800 RPM
Displacement : 3.2 L
Number of Cylinders : 4
Cylinder Type : Wet Liner
Combustion Type : Direct Injection

SDEC 4ZT3.2-G21 G-Drive Engine

Prime Power : 42 kW @ 1800 RPM
Displacement : 3.2 L
Number of Cylinders : 4
Cylinder Type : Wet Liner
Combustion Type : Direct Injection

SDEC 4ZT3.5-G21 G-Drive Engine

Prime Power : 60 kW @ 1800 RPM
Displacement : 3.5 L
Number of Cylinders : 4
Cylinder Type : Wet Liner
Combustion Type : Direct Injection

SDEC 4ZT4.1-G21 G-Drive Engine

Prime Power : 70 kW @ 1800 RPM
Displacement : 4.1 L
Number of Cylinders : 4
Cylinder Type : Wet Liner
Combustion Type : Direct Injection

SDEC 4ZTAA4.1-G21 G-Drive Engine

Prime Power : 76 kW @ 1800 RPM
Displacement : 4.1 L
Number of Cylinders : 4
Cylinder Type : Wet Liner
Combustion Type : Direct Injection

SDEC 4ZTAA4.1-G31 G-Drive Engine

Prime Power : 80 kW @ 1800 RPM
Displacement : 4.1 L
Number of Cylinders : 4
Cylinder Type : Wet Liner
Combustion Type : Direct Injection

SDEC 3Z1.1-G41 G-Drive Engine

Prime Power : 16.8 kW @ 3000 RPM
Displacement : 1.1 L
Number of Cylinders : 3
Cylinder Type : Wet Liner
Combustion Type : Direct Injection

SDEC 3Z1.1-G42 G-Drive Engine

Prime Power : 12 kW @ 1800 RPM
Displacement : 1.1 L
Number of Cylinders : 3
Cylinder Type : Wet Liner
Combustion Type : Direct Injection

SDEC 3ZT1.1-G41 G-Drive Engine

Prime Power : 25 kW @ 3000 RPM
Displacement : 1.1 L
Number of Cylinders : 3
Cylinder Type : Wet Liner
Combustion Type : Direct Injection

SDEC 3ZT1.1-G42 G-Drive Engine

Prime Power : 15.5 kW @ 1800 RPM
Displacement : 1.1 L
Number of Cylinders : 3
Cylinder Type : Wet Liner
Combustion Type : Direct Injection

SDEC 4Z2.9-G41 G-Drive Engine

Prime Power : 30 kW @ 1800 RPM
Displacement : 2.9 L
Number of Cylinders : 4
Cylinder Type : Wet Liner
Combustion Type : Direct Injection

SDEC 4Z2.9-G42 G-Drive Engine

Prime Power : 26 kW @ 1800 RPM
Displacement : 2.9 L
Number of Cylinders : 4
Cylinder Type : Wet Liner
Combustion Type : Direct Injection

SDEC 4Z2.9-G43 G-Drive Engine

Prime Power : 21 kW @ 1800 RPM
Displacement : 2.9 L
Number of Cylinders : 4
Cylinder Type : Wet Liner
Combustion Type : Direct Injection

SDEC 4Z2.9-G410 G-Drive Engine

Prime Power : 30 kW @ 1800 RPM
Displacement : 2.9 L
Number of Cylinders : 4
Cylinder Type : Wet Liner
Combustion Type : Direct Injection

SDEC 4Z2.9-G420 G-Drive Engine

Prime Power : 26 kW @ 1800 RPM
Displacement : 2.9 L
Number of Cylinders : 4
Cylinder Type : Wet Liner
Combustion Type : Direct Injection

SDEC 4Z2.9-G430 G-Drive Engine

Prime Power : 21 kW @ 1800 RPM
Displacement : 2.9 L
Number of Cylinders : 4
Cylinder Type : Wet Liner
Combustion Type : Direct Injection

SDEC 4Z3.2-G41 G-Drive Engine

Prime Power : 21 kW @ 1800 RPM
Displacement : 3.2 L
Number of Cylinders : 4
Cylinder Type : Wet Liner
Combustion Type : Direct Injection

SDEC 4Z3.2-G42 G-Drive Engine

Prime Power : 36 kW @ 1800 RPM
Displacement : 3.2 L
Number of Cylinders : 4
Cylinder Type : Wet Liner
Combustion Type : Direct Injection

SDEC 4ZTAA3.2-G31 G-Drive Engine

Prime Power : 70 kW @ 1800 RPM
Displacement : 3.2 L
Number of Cylinders : 4
Cylinder Type : Wet Liner
Combustion Type : Direct Injection

SDEC 4ZTAA3.2-G32 G-Drive Engine

Prime Power : 60 kW @ 1800 RPM
Displacement : 3.2 L
Number of Cylinders : 4
Cylinder Type : Wet Liner
Combustion Type : Direct Injection

SDEC 4ZTAA3.2-G33 G-Drive Engine

Prime Power : 49 kW @ 1800 RPM
Displacement : 3.2 L
Number of Cylinders : 4
Cylinder Type : Wet Liner
Combustion Type : Direct Injection

SDEC 4ZTAA3.2-G34 G-Drive Engine

Prime Power : 64 kW @ 1800 RPM
Displacement : 3.2 L
Number of Cylinders : 4
Cylinder Type : Wet Liner
Combustion Type : Direct Injection

SDEC 4ZTAA3.5-G31 G-Drive Engine

Prime Power : 74 kW @ 1800 RPM
Displacement : 3.5 L
Number of Cylinders : 4
Cylinder Type : Wet Liner
Combustion Type : Direct Injection

Mitsubishi S12R-PTA-C G-Drive Engine

Mitsubishi S12R-PTA-C G-Drive Engine

Rated Power: 1000KW @ 1800 RPM
Displacement : 49.03 L
Number of Cylinders : 6
Cylinder Type : Wet Liner
Combustion Type : Direct Injection

Mitsubishi S16R-PTA2-C G-Drive Engine

Mitsubishi S16R-PTA2-C G-Drive Engine

Rated Power: 1500KW @ 1500 RPM
Displacement : 65.37 L
Number of Cylinders :16
Cylinder Type : Wet Liner
Combustion Type : Direct Injection

Marine Engine

D Marine Main148-349 HP
E Marine Main271-494 HP
G Marine Main236-484 HP
H Marine Main76-224 HP
K Marine Main402-854 HP
W Marine Main854-966 HP
D Marine Auxiliary117-223 kW
E Marine Auxiliary236-334 kW
G Marine Auxiliary302-346 kW
H Marine Auxiliary60-168 kW
K Marine Auxiliary353-686 kW
W Marine Auxiliary490-668 kW
S6R2 Marine Auxiliary575-645 kW
S12R Marine Auxiliary1080-1277 kW
S16R Marine Auxiliary1600 kW
S16R2 Marine Auxiliary1684-1960 kW

Engine Model

Power/HP & kW

03006009001200150018002100
Emission Srandard:Euro ⅠEuro ⅡEuro ⅢEuro ⅣEuro ⅤEuro ⅥEuro Ⅶ
SDEC Marine Main Engine Catalogue
Series
Model
SC9D180.15CA1 | 148 HP @ 1500 RPMSC9D200.15CA1 | 197 HP @ 1500 RPMSC9D220.15CA1 | 217 HP @ 1500 RPMSC9D220.18CA1 | 217 HP @ 1800 RPM
 SC9D240.15CA1 | 236 HP @ 1500 RPM SC9D250.18CA1 | 247 HP @ 1800 RPMSC9D260.15CA1 | 262 HP @ 1500 RPM SC9D280.15CA1 | 276 HP @ 1500 RPM
 SC9D280.18CA1 | 276 HP @ 1800 RPM SC9D280.21CA1 | 276 HP @ 2100 RPMSC9D300.15CA1 | 295 HP @ 1500 RPM SC9D300.21CA1 | 295 HP @ 2100 RPM
 SC9D300.23CA1 | 295 HP @ 2300 RPM SC9D320.18CA1 | 315 HP @ 1800 RPMSC9D340.21CA1 | 335 HP @ 2100 RPM SC9D200.15CA2 | 193 HP @ 1500 RPM
 SC9D240.15CA2 | 231 HP @ 1500 RPM SC9D240.21CA2 | 231 HP @ 2100 RPMSC9D250.18CA2 | 241 HP @ 1800 RPM SC9D280.15CA2 | 271 HP @ 1500 RPM
 SC9D280.18CA2 | 271 HP @ 1800 RPM SC9D280.21CA2 | 271 HP @ 2100 RPMSC9D300.15CA2 | 290 HP @ 1500 RPM SC9D300.18CA2 | 290 HP @ 1800 RPM
 SC9D300.21CA2 | 290 HP @ 2100 RPM SC9D300.23CA2 | 290 HP @ 2300 RPMSC9D320.18CA2 | 308 HP @ 1800 RPM SC9D340.21CA2 | 329 HP @ 2100 RPM
SC9D340.23CA2 | 335 HP @ 2300 RPMSC9D360.23CA2 | 349 HP @ 2330 RPM
SC12E300.15CA1 | 295 HP @ 1500 RPMSC12E360.15CA1 | 355 HP @ 1500 RPMSC12E360.18CA1 | 355 HP @ 1800 RPMSC12E360.21CA1 | 355 HP @ 2100 RPM
SC12E400.18CA1 | 394 HP @ 1800 RPMSC12E400.21CA1 | 394 HP @ 2100 RPMSC12E420.18CA1 | 425 HP @ 1800 RPMSC12E420.21CA1 | 425 HP @ 2100 RPM
SC12E460.21CA1 | 456 HP @ 2100 RPMSC12E280.15CA2 | 271 HP @ 1500 RPMSC12E280.18CA2 | 271 HP @ 1800 RPMSC12E300.15CA2 | 288 HP @ 1500 RPM
SC12E300.18CA2 | 288 HP @ 1800 RPMSC12E330.15CA2 | 319 HP @ 1500 RPMSC12E330.18CA2 | 319 HP @ 1800 RPMSC12E360.18CA2 | 349 HP @ 1800 RPM
SC12E360.21CA2 | 349 HP @ 2100 RPM SC12E400.18CA2 | 386 HP @ 1800 RPMSC12E400.21CA2 | 386 HP @ 2100 RPMSC12E420.15CA2 | 355 HP @ 1500 RPM
SC12E460.18CA2 | 456 HP @ 1800 RPMSC12E460.21CA2 | 448 HP @ 2100 RPMSC13E420.15CA2 | 413 HP @ 1500 RPMSC13E420.18CA2 | 413 HP @ 1800 RPM
SC13E460.18CA2 | 448 HP @ 1800 RPMSC13E500.15CA2 | 484 HP @ 1500 RPMSC13E500.18CA2 | 484 HP @ 1800 RPMSC13E560.18CA2 | 494 HP @ 1800 RPM
 SC15G250.15CA1 | 236 HP @ 1500 RPM SC15G250.18CA1 | 236 HP @ 1800 RPM SC15G310.15CA1 | 298 HP @ 1500 RPM SC15G310.18CA1 | 298 HP @ 1800 RPM
 SC15G340.18CA1 | 329 HP @ 1800 RPM SC15G360.15CA1 | 351 HP @ 1500 RPM SC15G380.15CA1 | 367 HP @ 1500 RPMSC15G400.15CA1 | 386 HP @ 1800 RPM
SC15G400.18CA1 | 386 HP @ 2100 RPMSC15G420.15CA1 | 405 HP @ 1500 RPMSC15G420.18CA1 | 405 HP @ 1800 RPMSC15G460.15CA1 | 447 HP @ 1500 RPM
SC15G460.18CA1 | 447 HP @ 1800 RPMSC15G500.18CA1 | 484 HP @ 1800 RPM
SC4H80.15CA2 | 76 HP @ 1500 RPMSC4H100.15CA2 | 97 HP @ 1500 RPMSC4H120.15CA2 | 118 HP @ 1500 RPMSC4H120.18CA2 | 115 HP @ 1800 RPM
SC4H140.18CA2 | 131 HP @ 1800 RPMSC4H100CA | 89 HP @ 1500 RPMSC4H110CA | 98 HP @ 1800 RPMSC4H125CA2 | 110 HP @ 1500 RPM
SC4H140CA2 | 125 HP @ 1500 RPMSC4H155CA2 | 138 HP @ 1500 RPMSC4H170CA2 | 152 HP @ 1800 RPMSC7H120.15CA2 | 115 HP @ 1500 RPM
SC7H140.15CA2 | 135 HP @ 1500 RPMSC7H140.18CA2 | 135 HP @ 1800 RPMSC7H160.15CA2 | 156 HP @ 1500 RPMSC7H160.18CA2 | 156 HP @ 1800 RPM
SC7H170.21CA2 | 165 HP @ 2100 RPMSC7H175CA2 | 154 HP @ 1500 RPMSC7H180.15CA2 | 173 HP @ 1500 RPMSC7H180.18CA2 | 173 HP @ 1800 RPM
 SC7H180.23CA2 | 173 HP @ 2300 RPM SC7H190.21CA2 | 182 HP @ 2100 RPM SC7H195CA2 | 173 HP @ 1500 RPM SC7H200.18CA2 | 193 HP @ 1800 RPM
SC7H200.23CA2 | 193 HP @ 2300 RPMSC7H210.21CA2 | 201 HP @ 2100 RPMSC7H220CA2 | 193 HP @ 1800 RPMSC7H230.23CA2 | 223 HP @ 2300 RPM
 SC7H235CA2 | 208 HP @ 2100 RPM SC7H250CA2 | 224 HP @ 2300 RPM
SC25K410.13CA1 | 402 HP @ 1350 RPMSC25K450.13CA1 | 444 HP @ 1350 RPMSC25K480.13CA1 | 473 HP @ 1350 RPMSC25K540.13CA1 | 536 HP @ 1350 RPM
SC25K580.13CA1 | 571 HP @ 1350 RPMSC25K620.13CA1 | 612 HP @ 1350 RPMSC25K620.15CA1 | 599 HP @ 1500 RPMSC25K650.18CA1 | 628 HP @ 1800 RPM
SC25K670.13CA1 | 644 HP @ 1350 RPMSC25K700.18CA1 | 677 HP @ 1800 RPMSC25K760.13CA21 | 731 HP @ 1350 RPMSC25K760.15CA1 | 731 HP @ 1500 RPM
SC25K760.18CA1 | 731 HP @ 1800 RPMSC25K800.15CA1 | 772 HP @ 1800 RPMSC25K800.18CA1 | 772 HP @ 1800 RPMSC25K880.15CA21 | 854 HP @ 1500 RPM
 SC25K880.18CA21 | 854 HP @ 1800 RPM
SC38W880.12CA1 | 854 HP @ 1200 RPMSC38W950.12CA1 | 920 HP @ 1200 RPMSC38W1000.12CA1 | 966 HP @ 1200 RPM
——END——
SDEC Marine Auxiliary Engine Catalogue
Series
Model
SC9D245.15CF2 | 177 kW @ 1500 RPMSC9D260.15CF2 | 189 kW @ 1500 RPMSC9D310.15CF2 | 223 kW @ 1500 RPM
SC12E330.15CF1 | 241 kW @ 1500 RPMSC12E360.15CF1 | 265 kW @ 1500 RPMSC12E410.15CF1 | 301 kW @ 1500 RPMSC12E430.15CF1 | 318 kW @ 1500 RPM
SC12E330.15CF2 | 236 kW @ 1500 RPMSC12E410.15CF2 | 295 kW @ 1500 RPMSC12E460.15CF2 | 334 kW @ 1500 RPM
 SC15G420.15CF1 | 302 kW @ 1500 RPM SC15G480.15CF1 | 346 kW @ 1800 RPM
SC4H85.15CF2 | 60 kW @ 1500 RPMSC4H105.15CF2 | 75 kW @ 1500 RPMSC4H125.15CF2 | 90 kW @ 1500 RPMSC4H140.15CF2 | 101 kW @ 1500 RPM
SC4H165.15CF2 | 119 kW @ 1500 RPMSC4H85.15CF1 | 62 kW @ 1500 RPMSC4H95CF2 | 62 kW @ 1500 RPMSC4H100CD | 65 kW @ 1500 RPM
SC4H105.15CF1 | 78 kW @ 1500 RPMSC4H115CF2 | 78 kW @ 1500 RPMSC4H130CD | 87 kW @ 1500 RPMSC4H140CF2 | 93 kW @ 1500 RPM
SC4H150CD | 98 kW @ 1500 RPMSC4H160CF2 | 105 kW @ 1500 RPM SC4H180CF2 | 120 kW @ 1500 RPMSC7H170.15CF2 | 123 kW @ 1500 RPM
SC7H185CF2 | 124 kW @ 1500 RPMSC7H195CD | 129 kW @ 1500 RPMSC7H200.15CF2 | 144 kW @ 1500 RPMSC7H230CD | 154 kW @ 1500 RPM
 SC7H230.15CF2 | 167 kW @ 1500 RPM SC7H250CF2 | 168 kW @ 1500 RPM
SC25K490.10CF1 | 353 kW @ 1000 RPMSC25K570.10CF1 | 412 kW @ 1000 RPMSC25K570.15CF1 | 412 kW @ 1500 RPMSC25K650.10CF1 | 471 kW @ 1000 RPM
SC25K650.15CF1 | 471 kW @ 1500 RPMSC25K730.15CF1 | 592 kW @ 1500 RPMSC25K820.15CF1 | 588 kW @ 1500 RPMSC25K950.15CF21 | 686 kW @ 1500 RPM
SC38W680.10CF1 | 490 kW @ 1000 RPMSC38W770.10CF1 | 554 kW @ 1000 RPMSC38W825.10CF1 | 593 kW @ 1000 RPMSC38W930.10CF1 | 668 kW @ 1000 RPM
S6R2-PTA-C | 575 kW @ 1500 RPMS6R2-PTAA-C | 645 kW @ 1500 RPM
 S12R-PTA-C | 1080 kW @ 1500 RPM S12R2-PTA2-C | 1165 kW @ 1500 RPM S12R-PTAA2-C | 1277 kW @ 1500 RPM
 S16R-PTA2-C | 1600 kW @ 1500 RPM
S16R2-PTAW-C | 1960 kW @ 1500 RPMS16R2-PTAA2-C | 1684 kW @ 1500 RPM
——END——

SDEC SC9D180.15CA1 Marine Engine

Prime Power : 110 kW @ 1500 RPM
Number of Cylinders : 6
Aspiration : TC & Intercooled
Displacement : 8.82 L
Dry Weight : 900 Kg

SDEC SC9D200.15CA1 Marine Engine

Prime Power : 162 kW @ 1500 RPM
Number of Cylinders : 6
Aspiration : TC & Intercooled
Displacement : 8.82 L
Dry Weight : 900 Kg

SDEC SC9D220.15CA1 Marine Engine

Prime Power : 162 kW @ 1500 RPM
Number of Cylinders : 6
Aspiration : TC & Intercooled
Displacement : 8.82 L
Dry Weight : 900 Kg

SDEC SC9D220.18CA1 Marine Engine

Prime Power : 162 kW @ 1800 RPM
Number of Cylinders : 6
Aspiration : TC & Intercooled
Displacement : 8.82 L
Dry Weight : 900 Kg

SDEC SC9D240.15CA1 Marine Engine

Prime Power : 176 kW @ 1500 RPM
Number of Cylinders : 6
Aspiration : TC & Intercooled
Displacement : 8.82 L
Dry Weight : 900 Kg

SDEC SC9D250.18CA1 Marine Engine

Prime Power : 184 kW @ 1800 RPM
Number of Cylinders : 6
Aspiration : TC & Intercooled
Displacement : 8.82 L
Dry Weight : 900 Kg

SDEC SC9D260.15CA1 Marine Engine

Prime Power : 192 kW @ 1500 RPM
Number of Cylinders : 6
Aspiration : TC & Intercooled
Displacement : 8.82 L
Dry Weight : 900 Kg

SDEC SC9D280.15CA1 Marine Engine

Prime Power : 206 kW @ 1500 RPM
Number of Cylinders : 6
Aspiration : TC & Intercooled
Displacement : 8.82 L
Dry Weight : 900 Kg

SDEC SC9D280.18CA1 Marine Engine

Prime Power : 206 kW @ 1500 RPM
Number of Cylinders : 6
Aspiration : TC & Intercooled
Displacement : 8.82 L
Dry Weight : 900 Kg

SDEC SC9D280.21CA1 Marine Engine

Prime Power : 206 kW @ 2100 RPM
Number of Cylinders : 6
Aspiration : TC & Intercooled
Displacement : 8.82 L
Dry Weight : 900 Kg

SDEC SC9D300.15CA1 Marine Engine

Prime Power : 220 kW @ 1500 RPM
Number of Cylinders : 6
Aspiration : TC & Intercooled
Displacement : 8.82 L
Dry Weight : 900 Kg

SDEC SC9D300.21CA1 Marine Engine

Prime Power : 220 kW @ 2100 RPM
Number of Cylinders : 6
Aspiration : TC & Intercooled
Displacement : 8.82 L
Dry Weight : 900 Kg

SDEC SC9D300.23CA1 Marine Engine

Prime Power : 220 kW @ 2300 RPM
Number of Cylinders : 6
Aspiration : TC & Intercooled
Displacement : 8.82 L
Dry Weight : 900 Kg

SDEC SC9D320.18CA1 Marine Engine

Prime Power : 235 kW @ 1800 RPM
Number of Cylinders : 6
Aspiration : TC & Intercooled
Displacement : 8.82 L
Dry Weight : 900 Kg

SDEC SC9D340.21CA1 Marine Engine

Prime Power : 250 kW @ 2100 RPM
Number of Cylinders : 6
Aspiration : TC & Intercooled
Displacement : 8.82 L
Dry Weight : 900 Kg

SDEC SC9D340.23CA1 Marine Engine

Prime Power : 250 kW @ 2300 RPM
Number of Cylinders : 6
Aspiration : TC & Intercooled
Displacement : 8.82 L
Dry Weight : 900 Kg

SDEC SC4H100CA Marine Engine

SDEC SC4H100CA Marine Engine

Prime Power : 66 kW @ 1500 RPM
Number of Cylinders : 4
Aspiration : Supercharge
Displacement : 4.29 L
Dry Weight : 495 Kg

SDEC SC4H100CA Marine Engine

SDEC SC4H110CA Marine Engine

Prime Power : 73 kW @ 1800 RPM
Number of Cylinders : 4
Aspiration : Supercharge
Displacement : 4.29 L
Dry Weight : 495 Kg

SDEC SC4H80.15CA2 Marine Engine

SDEC SC4H80.15CA2 Marine Engine

Prime Power : 57 kW @ 1500 RPM
Number of Cylinders : 4
Aspiration : TC & Intercooled
Displacement : 4.3 L
Dry Weight : 460 Kg

SDEC SC4H125CA2 Marine Engine

SDEC SC4H125CA2 Marine Engine

Prime Power : 82 kW @ 1500 RPM
Number of Cylinders : 4
Aspiration : TC & Intercooled
Displacement : 4.29 L
Dry Weight : 540 Kg

SDEC SC4H140CA2 Marine Engine

SDEC SC4H140CA2 Marine Engine

Prime Power : 93 kW @ 1500 RPM
Number of Cylinders : 4
Aspiration : TC & Intercooled
Displacement : 4.29 L
Dry Weight : 540 Kg

SDEC SC4H155CA2 Marine Engine

SDEC SC4H155CA2 Marine Engine

Prime Power : 103 kW @ 1500 RPM
Number of Cylinders : 4
Aspiration : TC & Intercooled
Displacement : 4.29 L
Dry Weight : 540 Kg

SDEC SC4H170CA2 Marine Engine

SDEC SC4H170CA2 Marine Engine

Prime Power : 113 kW @ 1800 RPM
Number of Cylinders : 4
Aspiration : TC & Intercooled
Displacement : 4.29 L
Dry Weight : 540 Kg

SDEC SC7H175CA2 Marine Engine

SDEC SC7H175CA2 Marine Engine

Prime Power :115 kW @ 1500 RPM
Number of Cylinders : 6
Aspiration : TC & Intercooled
Displacement : 6.44 L
Dry Weight : 675 Kg

SDEC SC7H195CA2 Marine Engine

SDEC SC7H195CA2 Marine Engine

Prime Power : 129 kW @ 1500 RPM
Number of Cylinders : 6
Aspiration : TC & Intercooled
Displacement : 4.29 L
Dry Weight : 675 Kg

SDEC SC7H200.18CA2 Marine Engine

SDEC SC7H200.18CA2 Marine Engine

Prime Power : 147 kW @ 1800 RPM
Number of Cylinders : 6
Aspiration : TC & Intercooled
Displacement : 6.44 L
Dry Weight : 675 Kg

SDEC SC7H220CA2 Marine Engine

SDEC SC7H220CA2 Marine Engine

Prime Power : 144 kW @ 1800 RPM
Number of Cylinders : 6
Aspiration : TC & Intercooled
Displacement : 6.44 L
Dry Weight : 675 Kg

SDEC SC7H235CA2 Marine Engine

SDEC SC7H235CA2 Marine Engine

Prime Power : 155 kW @ 2100 RPM
Number of Cylinders : 6
Aspiration : TC & Intercooled
Displacement : 6.44 L
Dry Weight : 675 Kg

SDEC SC7H250CA2 Marine Engine

SDEC SC7H250CA2 Marine Engine

Prime Power : 167 kW @ 2300 RPM
Number of Cylinders : 6
Aspiration : TC & Intercooled
Displacement : 6.44 L
Dry Weight : 675 Kg

SDEC SC4H130CD Auxiliary Engine

SDEC SC4H130CD Auxiliary Engine

Prime Power : 87 kW @ 1500 RPM
Number of Cylinders : 4
Aspiration : TC & Intercooled
Displacement : 4.29 L
Dry Weight : 495 Kg

SDEC SC4H150CD Auxiliary Engine

SDEC SC4H150CD Auxiliary Engine

Prime Power : 98 kW @ 1500 RPM
Number of Cylinders : 4
Aspiration : TC & Intercooled
Displacement : 4.29 L
Dry Weight : 540 Kg

SDEC SC4H160CF2 Auxiliary Engine

SDEC SC4H160CF2 Auxiliary Engine

Prime Power : 105 kW @ 1500 RPM
Number of Cylinders : 4
Aspiration : TC & Intercooled
Displacement : 4.29 L
Dry Weight : 540 Kg

SDEC SC4H160CF2 Auxiliary Engine

SDEC SC4H180CF2 Auxiliary Engine

Prime Power : 120 kW @ 1500 RPM
Number of Cylinders : 4
Aspiration : TC & Intercooled
Displacement : 4.29 L
Dry Weight : 540 Kg

SDEC SC7H195CD Auxiliary Engine

SDEC SC7H195CD Auxiliary Engine

Prime Power :129 kW @ 1500 RPM
Number of Cylinders : 6
Aspiration : TC & Intercooled
Displacement : 6.44 L
Dry Weight : 675 Kg

SDEC SC7H230CD Auxiliary Engine

SDEC SC7H230CD Auxiliary Engine

Prime Power :154 kW @ 1500 RPM
Number of Cylinders : 6
Aspiration : TC & Intercooled
Displacement : 6.44 L
Dry Weight : 675 Kg

SDEC SC7H235CA2 Marine Engine

SDEC SC7H235CA2 Marine Engine

Prime Power : 155 kW @ 2100 RPM
Number of Cylinders : 6
Aspiration : TC & Intercooled
Displacement : 6.44 L
Dry Weight : 675 Kg

SDEC Project Video

Years of History

Countries Covered

Production

SQM Modern Factory

Global Projects

Customer Review

Marine-Equipment-Supplier-in-Egypt

Egypt | Marine-Equipment Supplier Interview

SinoMac 2027 Customer Interview Video: Since 2023, SinoMac has completed a series of interviews with multiple enterprises from different countries and regions. Most of the videos were shot at the customer companies and factories, and all the evaluations and feedback about SinoMac were collected, covering different industries in different countries and regions. We believe that this series of SinoMac customer interview videos can help all other customers have a deeper understanding of SinoMac.

Indonesia-Customer

Indonesia | Pump-Manufacturer Interview

EMAC 2027 Customer Interview Video: Since 2023, EMAC has completed a series of interviews with multiple enterprises from different countries and regions. Most of the videos were shot at the customer companies and factories, and all the evaluations and feedback about EMAC were collected, covering different industries in different countries and regions.

Vietnam | Pump – Electric Motor

EMAC's customer interview video of 2024, EMAC finished a series of customer interview with 10 different business partners from different countries and regions, most of videos are took at customer's company and factory, collecting all reviews and evaluations of EMAC, covering different industries in different country and regions, we believe this series of EMAC customer interview videos can help all of other customers get to know more about EMAC, our true customer interview case can greatly help customers relieve their worries, and build their confidence to cooperate with EMAC. A Promise is A Promise, EMAC always do what we say, and for customer’s feedback, also 100% original from clients’s real words. EMAC, a Chinese company that you can trust!

Indonesia | Construction – Customer Interview

EMAC's customer interview video of 2025, EMAC finished a series of customer interview with 10 different business partners from different countries and regions, most of videos are took at customer's company and factory, collecting all reviews and evaluations of EMAC, covering different industries in different country and regions, we believe this series of EMAC customer interview videos can help all of other customers get to know more about EMAC, our true customer interview case can greatly help customers relieve their worries, and build their confidence to cooperate with EMAC. A Promise is A Promise, EMAC always do what we say, and for customer’s feedback, also 100% original from clients’s real words. EMAC, a Chinese company that you can trust!

Thailand | Pump – Equipment Production

EMAC's customer interview video of 2023, EMAC finished a series of customer interview with 10 different business partners from different countries and regions, most of videos are took at customer's company and factory, collecting all reviews and evaluations of EMAC, covering different industries in different country and regions, we believe this series of EMAC customer interview videos can help all of other customers get to know more about EMAC, our true customer interview case can greatly help customers relieve their worries, and build their confidence to cooperate with EMAC. A Promise is A Promise, EMAC always do what we say, and for customer’s feedback, also 100% original from clients’s real words. EMAC, a Chinese company that you can trust!

Malaysia | Construction – Ground Support Equipment

EMAC's customer interview video of 2023, EMAC finished a series of customer interview with 10 different business partners from different countries and regions, most of videos are took at customer's company and factory, collecting all reviews and evaluations of EMAC, covering different industries in different country and regions, we believe this series of EMAC customer interview videos can help all of other customers get to know more about EMAC, our true customer interview case can greatly help customers relieve their worries, and build their confidence to cooperate with EMAC. A Promise is A Promise, EMAC always do what we say, and for customer’s feedback, also 100% original from clients’s real words. EMAC, a Chinese company that you can trust!

Thailand | Pump – Thailand Engineering Company Interview

EMAC's customer interview video of 2023, EMAC finished a series of customer interview with 10 different business partners from different countries and regions, most of videos are took at customer's company and factory, collecting all reviews and evaluations of EMAC, covering different industries in different country and regions, we believe this series of EMAC customer interview

Indonesia | Marine – Indonesia Shipyard Interview

EMAC's customer interview video of 2023, EMAC finished a series of customer interview with 10 different business partners from different countries and regions, most of videos are took at customer's company and factory, collecting all reviews and evaluations of EMAC, covering different industries in different country and regions, we believe this series of EMAC customer interview videos can help all of other customers get to know more about EMAC, our true customer interview case can greatly help customers relieve their worries, and build their confidence to cooperate with EMAC.

EMACs-Customer-Review-A-Egypts-Company-FeedbackSize-180x120px

A Egypt’s | Marine – A Egypt’s Company Feedback.

You can count on EMAC in trems of commitment & quality. We are looking forward to make very good business with EMAC in the field of diesel engine, gearbox and spare parts.Since the year of 2021, we start business relationship with EMAC and they are the first Chinese company we are working with...

EMACs-Customer-Review-A-Safari-Boats-Operators-FeedbackSize-180x120px

Malaysia | Marine – Feedback from Safari Boat Operators

We were satisfied with EMAC, and happy to having them as our supplier, our boat has been operated for more than 5 years now, both propulsion system and power system from EMAC are working perfectly. We do happy with the good quality of products from EMAC, the stability...

News & Events

Technical Articles

Global Activity

SinoMac Makes Its Mark at Global Maritime Event—A Look Back at Marintec China 2025

Hailed as the "Olympics" of the global maritime industry, Marintec China 2025 took place from December 2 to 5, 2025, at the Shanghai New International Expo Centre. Centered on the theme “Innovation and Cooperation for Sustainable Maritime Development,” this edition showcased cutting-edge technologies, innovative achievements, and sustainable pathways across the global maritime sector. It attracted over 2,000 exhibiting companies and tens of thousands of professional visitors from more than 100 countries and regions, highlighting China's pivotal influence and open-cooperative stance within the global maritime industry.

SinoMac’s Presence at the 2025 Kazakhstan International Mining, Exploration & Coal Processing Exhibition

As one of the most influential mining exhibitions in Central Asia, the Kazakhstan International Mining, Exploration and Coal Processing Exhibition (Mining Week) was grandly held in Karaganda, Kazakhstan from June 24 to 26, 2025. Focused on the entire mining process, this exhibition showcased a concentrated display of technological innovations, equipment upgrades and green solutions-catering to the industry’s full-chain demands and serving as a premier platform for global mining players to showcase technologies, exchange experience and explore partnerships.

Review of SeaMac 2025 Vietnam International Maritime Ship Exhibition:Deeply connecting with the cutting-edge of the global maritime industry

Recently, the highly anticipated 2025 Vietnam International Maritime and Shipbuilding Exhibition concluded successfully at the Adora Convention Center in Ho Chi Minh City. As Vietnam’s largest and most specialized event in shipbuilding and maritime technology, the exhibition gathered top shipbuilders, maritime service providers, and marine equipment manufacturers from around the world. SeaMac actively participated, comprehensively showcasing its innovative achievements and integrated capabilities in ship solutions and high-efficiency propulsion systems. The company engaged in extensive and in-depth exchanges with industry partners, achieving fruitful outcomes from its participation.

Attending a Global Maritime Extravaganza, SinoMac will be showcasing at Marintec China 2025

Marintec China 2025, hailed as a "global trendsetter for the maritime industry," will be held from December 2nd to 5th, 2025, at the Shanghai New International Expo Centre. The theme of this year's exhibition is "Innovation and Cooperation for Sustainable Development of the Maritime Industry," and the theme of the High-Level Maritime Forum is "Intelligent Navigation, Green Coexistence, Integration, and Innovation," reflecting expectations for the industry's future. Global Maritime, SinoMac SinoMac, Global Maritime

Review SAUDI RAIL 2025 ：SinoMac Exhibition Highlights

SinoMac successfully participated in SAUDI RAIL 2025, the annual industry event held in Riyadh, Saudi Arabia, from October 19th to 20th, 2025. At the exhibition, SinoMac showcased its strong capabilities in railway technology, innovative solutions, and full lifecycle services, and engaged in in-depth exchanges with industry partners, customers, and experts from around the world to jointly explore future opportunities for rail transit development in the Middle East. Global Exhibition, SinoMac SinoMac, Global Exhibition

Deeply Cultivate the International Market, Empowering the Future of Rail ——Focus [PROMotion Expo 2025] SinoMac Exhibition Highlights Review

Deeply Cultivate the International Market, Empowering the Future of Rail ——Focus [PRO//Motion Expo 2025]: SinoMac Exhibition Highlights Review

From August 28 to 31, 2025, the highly anticipated PRO//Motion Expo 2025 (Russian International Railway and Motion Exhibition) grandly opened at the Russian Railway Museum in St. Petersburg. PRO//Motion Expo is currently the largest railway and transportation exhibition in Russia and the Commonwealth of Independent States (CIS), attracting extensive participation from railway companies from CIS countries and around the world. Over the four-day exhibition, exhibitors showcased cutting-edge technologies and innovative achievements in the railway transportation industry.

Focus on marine industry event, start a new chapter of marine development together–SinoMac Group Limited to exhibit at Marine & Offshore Vietnam 2025

Against the backdrop of the booming development of the global shipping and maritime industry, Vietnam International Maritime Expo 2025 (Marine & Offshore Vietnam) will be held in Ho Chi Minh City, Vietnam from 19th to 21st November. As one of the most influential maritime events in Southeast Asia, this exhibition brings together top enterprises and innovations in the fields of global shipbuilding, offshore engineering, port equipment, new energy ship technology, etc., and provides an international platform for industry colleagues to exchange and co-operate and explore the market.

SinoMac Group Limited made its debut at the 2025 Indonesia International Construction Machinery, Mining and Concrete Exhibition.

The International Exhibition of Engineering Machinery, Mining, and Concrete (Mining Indonesia) will be held in Jakarta, Indonesia, from September 17 to 20, 2025. As one of the most influential mining exhibitions in Southeast Asia, Mining Indonesia provides a professional platform for enterprises, experts, and practitioners in the global mining sector to showcase cutting-edge technologies, exchange industry insights, and explore collaborative opportunities.

premade-image-1

Subscribe To Our Newsletter

Subscribe to get the latest updates from www.sdec-engine.com

You have Successfully Subscribed!

Pin It on Pinterest
