Rated Power: 205 kW @ 1800 RPM
Displacement : 8.82 L
Number of Cylinders : 6
Cylinder Type : Wet Liner
Combustion Type : Direct Injection
SDEC D Generator Drive Engine
The D-Series engine was designed jointly with AVL of Austria, and in 2005, in cooperation with the Southwest Research Institute (SwRI) of the United States, the design was enhanced and the four-valve upgrade was carried out.
This series of engines has the characteristics of high reliability and good fuel economy, is a mature engine in the domestic design age, advanced technical indicators of the engine, has been selling for nearly 20 years, the market has more than 1 million units.
Four-valve structure, high-strength body, integral cylinder head design, key components using international first-class brands, high reliability, good economy.
According to SAIC MOTOR manufacturing standards, Volkswagen engine quality control system guarantees high product quality and good consistency.
The whole structure adopts the integrated parts design, the basic parts are 20 % less than the general diesel engine, the structure is simple and the maintenance is convenient.
Without the intake heating auxiliary device, the cold starting temperature is -15 ℃, and the starting temperature is -30 ℃ with the auxiliary device, which has strong environmental adaptability.
General Specifications of D G-Drive Engine
| Engine Type: | 6 Cylinders |
| Displacement: | 8.82 L |
| Rated Speed: | 1500 – 1800 RPM |
| Emission Standard: | Euro III |
| Fuel System: | Direct injection |
| Standby Power: | 204 – 282 kW @ 1500 – 1800 RPM |
| Prime Power: | 185 – 255 kW @ 1500 – 1800 RPM |
| Bore * Stroke: | 114 mm * 144 mm |
| Dry Weight: | 740 – 900 kg |
| Packing Size(L * W * H): | N/A |
SDEC D Series G-Drive Engine
This list including all models of SDEC D Series G-Drive Engine.
Click here to find G-Drive engines by type (Engine Speed).
SDEC 6DTAA8.9-G23 G-Drive Engine
Prime Power: 255 kW @ 1800 RPM
Displacement : 8.82 L
Number of Cylinders : 6
Cylinder Type : Wet Liner
Combustion Type : Direct Injection
SDEC 6DTAA8.9-G24 G-Drive Engine
Prime Power: 228 kW @ 1800 RPM
Displacement : 8.82 L
Number of Cylinders : 6
Cylinder Type : Wet Liner
Combustion Type : Direct Injection
SDEC 6DTAA8.9-G31 G-Drive Engine
Prime Power: 205 kW @ 1800 RPM
Displacement : 8.82 L
Number of Cylinders : 6
Cylinder Type : Wet Liner
Combustion Type : Direct Injection
SDEC 6DTAA8.9-G32 G-Drive Engine
Prime Power: 235 kW @ 1800 RPM
Displacement : 8.82 L
Number of Cylinders : 6
Cylinder Type : Wet Liner
Combustion Type : Direct Injection
SDEC 6DTAA8.9-G33 G-Drive Engine
Prime Power: 255 kW @ 1800 RPM
Displacement : 8.82 L
Number of Cylinders : 6
Cylinder Type : Wet Liner
Combustion Type : Direct Injection
SDEC 6DTAA8.9-G34 G-Drive Engine
Prime Power: 255 kW @ 1800 RPM
Displacement : 8.82 L
Number of Cylinders : 6
Cylinder Type : Wet Liner
Combustion Type : Direct Injection
SDEC SC8D280D2 G-Drive Engine
Prime Power: 185 kW @ 1500 RPM
Displacement : 8.27 L
Number of Cylinders : 6
Cylinder Type : Wet Liner
Combustion Type : Direct Injection
SDEC SC9D310D2 G-Drive Engine
Prime Power: 208 kW @ 1500 RPM
Displacement : 8.82 L
Number of Cylinders : 6
Cylinder Type : Wet Liner
Combustion Type : Direct Injection
SDEC SC9D340D2 G-Drive Engine
Prime Power: 208 kW @ 1500 RPM
Displacement : 8.82 L
Number of Cylinders : 6
Cylinder Type : Wet Liner
Combustion Type : Direct Injection
